Airtac 2WT Extra High Flow Solenoid Valve 2WT050-10-C
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-10-C High Flow Solenoid Valve Specifications
- Model: 2WT050-10-C
- Type: 5/2-way direct acting (monostable)
- Port size: G3/8 (DN10 equivalent)
- Flow capacity: 8500 Nl/min (Cv=2.3)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.25kg ±5%
- Dimensions: 182mm(L) × 68mm(W) × 62mm(H)
- Valve body material: Die-cast aluminum alloy (anodized)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: 5.5W (DC), 6.8VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥50 million cycles (under rated conditions)
High-flow solenoid valve with optimized flow path geometry for rapid cylinder actuation. Features double-coil heat dissipation design with overcurrent protection. Includes manual override button for system debugging. Requires 5μm filtered dry air (lubricated or non-lubricated). Compatible with vacuum applications when paired with EPDM seals (optional).
- High-speed packaging machinery (cartoning, filling lines)
- Pressurized industrial cleaning systems
- Automotive welding fixture controls
- Plastic injection molding machine ejectors
- Pneumatic conveyor switching valves
- Test bench flow control systems
Installation guidelines:
Mount with vibration-damping brackets in high-cycle applications.
Maintain minimum 30cm distance from high-frequency inverters.
Use copper-free lubricant if manual operation is stiff at low temperatures.
| Property | Property Value |
|---|---|
| sku | 2WT050-10-C |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC 110V |
