Airtac 2WX Fluid Solenoid Valve 2WX05010CI
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010CI Fluid Solenoid Valve Specifications
- Model: 2WX05010CI
- Type: 5/2-way single solenoid (monostable)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 450g ±5% (with coil)
- Dimensions: 70mm(L) × 40mm(W) × 100mm(H)
- Flow capacity: 750 l/min (Cv=1.2 at 0.5 MPa)
- Seal material: NBR standard (FKM optional)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤20ms (at rated voltage)
- Power consumption: 2.8W (DC24V), 3.5VA (AC220V)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
- Max. switching frequency: 5Hz (lubricated air)
High-flow proportional solenoid valve with precision-machined spool structure, optimized for bidirectional cylinder control in industrial automation. Features aluminum alloy body with hard anodized finish for chemical resistance. Requires ISO 8573-1 class 3 (40μm) filtered compressed air with oil mist lubrication (ISO VG32 recommended).
- Pneumatic press clamping systems
- Automated assembly line actuators
- Textile machinery cylinder control
- Plastic injection molding ejectors
- Food processing pneumatic circuits (food-grade version available)
Installation guidelines:
Mount horizontally with arrow aligned to flow direction. Use shock-absorbing
brackets in high-vibration environments. Allow 20mm clearance for manual override
operation. Perform monthly air moisture purging in humid environments.
| Property | Property Value |
|---|---|
| sku | 2WX05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
