Airtac 300M Solenoid Valve Manifold 300M-13F
$60.19
Regular price
$67.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
300M-13F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Enables integration of directional control valves from the same series into a compact manifold assembly, achieving space optimization and cost-effectiveness;
2、Centralized air supply/exhaust ports and unified wiring layout simplify troubleshooting during system failures;
3、Modular design with high scalability allows flexible combination and future expansion of connected directional control valves;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 300M
Installation note:
Apply silicone-free grease to O-rings before assembly.
Torque mounting screws to 0.5-0.6 N·m in crisscross pattern.
Maximum recommended stack height: 6 valves per manifold.
2、Centralized air supply/exhaust ports and unified wiring layout simplify troubleshooting during system failures;
3、Modular design with high scalability allows flexible combination and future expansion of connected directional control valves;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 300M
AirTAC 300M-13F Valve Manifold Base Specifications
- Model: 300M-13F
- Type: Modular solenoid valve manifold base
- Port size: 1/8" NPT (G1/8 optional)
- Compatible valves: 300 series solenoid valves
- Material: Reinforced black PBT+30%GF
- Mounting pattern: ISO 15407-1 compliant
- Operating temperature: -20℃ to 80℃
- Max pressure: 1.0 MPa
- Weight: 220g ±5%
- Dimensions: 132mm(L) × 22mm(W) × 36mm(H)
- Seal compatibility: Works with NBR/FKM seals
- Surface finish: Ra 3.2μm (fluid passages)
Precision-molded manifold base featuring staggered port design for minimized pressure drop. Integrated O-ring grooves ensure leak-free stacking of multiple valves. Compatible with 300 series sub-bases for custom manifold configurations. Includes M5 mounting threads on both ends.
Typical Applications:
- Multi-valve pneumatic control stations
- Automated assembly line tooling
- Textile machinery air circuits
- Plastic injection molding systems
- Semiconductor handling equipment
Installation note:
Apply silicone-free grease to O-rings before assembly.
Torque mounting screws to 0.5-0.6 N·m in crisscross pattern.
Maximum recommended stack height: 6 valves per manifold.
| Property | Property Value |
|---|---|
| sku | 300M-13F |
