Airtac 3A100 Pneumatic Control Valve 3A110-06NC
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Double pneumatic pilot control features inherent memory function;
3. Precision-engineered internal bore minimizes friction resistance, enabling low actuation pressure and extended service life;
4. Maintenance-free operation without lubrication required;
5. Supports versatile mounting orientations for simplified installation and operation;
6. Compatible with modular valve base integration to optimize space utilization.
Category: Pneumatic Pilot Valves, Brand: AirTAC, Series: 3A100
AirTAC 3A100 Series 3A110-06NC Air Control Valve Technical Details
- Model: 3A110-06NC
- Type: 3/2-way normally closed (pilot-operated air control)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–1.0 MPa
- Max flow capacity: 850 L/min (ANR)
- Actuation type: Pneumatic pilot control (requires 0.3MPa min. pilot pressure)
- Response time: ≤0.1s (at 0.5MPa)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -20℃ to 80℃ (with silicone seals optional for high-temp)
- Body material: Anodized aluminum alloy (ISO 1C1 corrosion rating)
- Weight: 320g ±5% (including accessories)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H) (excluding mounting hardware)
- Port thread depth: 10mm (tapered pipe thread ISO 7-1)
- Leakage rate: ≤3 bubbles/min (per JIS B8379 standard)
- Cycle life: ≥5 million operations (under rated conditions)
- Protection rating: IP67 (dust-tight and waterproof immersion up to 1m)
High-flow pneumatic control valve with mechanical latching capability, featuring dual-port exhaust design for rapid cylinder movement. The hardened stainless steel shaft and wear-compensating seals ensure stable performance in high-cycle applications. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 4.4.3 air quality (max 40mg/m³ oil content).
- High-speed stamping press clutches
- Plastic injection molding machine ejectors
- Automated assembly line gripper systems
- Foundry equipment pneumatic circuits
- Textile machinery air distribution
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
For horizontal installation, orient exhaust ports downward to prevent
debris accumulation. Perform monthly lubrication of external
linkages using ISO VG32 pneumatic tool oil.
| Property | Property Value |
|---|---|
| sku | 3A110-06NC |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Port Size | PT1/8 |
