Airtac 3V-F Base 3V100M10F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V100M10F Base Unit Technical Specifications
- Model: 3V100M10F (3V-F Series Modular Base)
- Type: ISO 5599-1 Standard Modular Valve Base
- Port configuration: 10 ports (5 stations × 2 ports)
- Port thread: G1/8 (BSPP) with O-ring seal
- Max operating pressure: 1.0 MPa
- Material: Glass fiber reinforced PA66
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃
- Weight: 280g ±5g
- Dimensions: 100mm(L) × 34mm(W) × 42mm(H)
- Mounting: DIN rail (35mm) or direct screw mounting
- Compatibility: Works with 3V210/3V310/3V410 series valves
Robust modular base designed for multi-valve manifold assemblies in compact pneumatic systems. Features integrated air passageways for simplified piping, with color-coded port indicators (P=pressure, R=exhaust, A/B=actuator ports). Sealing structure prevents cross-leakage between adjacent valves.
- Automated assembly line valve clusters
- Packaging machinery multi-axis control
- Robotic end-effector pneumatic systems
- Plastic injection molding machine manifolds
- Semiconductor handling equipment
Installation tip:
Apply 0.5-0.8Nm torque during valve mounting. Use compatible grease
(Parker O-Lube 3 recommended) on seals. Maximum stacking: 20 bases.
| Property | Property Value |
|---|---|
| sku | 3V100M10F |
