Airtac 3V1 Solenoid Valve 3V1M5A
The AirTAC Airtac 3V1 Solenoid Valve 3V1M5A is a genuine 3-port 2-position (3/2) solenoid valve with M5 ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Port sizeM5
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Series3V1
About the Airtac 3V1 Solenoid Valve 3V1M5A
AirTAC 3V1M5A pairs the smallest 3V1 body with an M5 port and an AC220V coil drawing just 4.5 VA. The direct-acting design needs no minimum pressure differential to shift, and the spring returns it whenever power drops, feeding or venting a single line.
That low 4.5 VA draw lets one small transformer run many valves across a machine. A DIN plug connector, IP65 (DIN 40050) sealing and a manual override keep installation and fault-finding straightforward, while the 40 um filtration requirement protects the internal clearances.
Airtac 3V1 Solenoid Valve 3V1M5A Technical Specifications
| Model | Airtac 3V1 Solenoid Valve 3V1M5A |
|---|---|
| Series | 3V1 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Port size | M5 |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 4.5 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Not published for 3V1 |
| Temperature | -20 to 70 C |
| Construction | Direct-acting, single solenoid, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V1 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V1 Solenoid Valve 3V1M5A
| 3V1 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| M5 | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V1 Solenoid Valve 3V1M5A Is Used
Jig and fixture clamping
Actuates a small spring-return clamp cylinder that holds a machined part against a locator while it is drilled or tapped.
Pilot stage for a process valve
Supplies the pilot signal that shifts a larger main air valve in a compact control cabinet, its M5 port suiting tight manifolds.
Sorting chute diverters
Feeds the single-acting air cylinder that flips a diverter flap on a bottling-line conveyor, venting it between pushes.
Is the Airtac 3V1 Solenoid Valve 3V1M5A the Right Part?
Start from the coil: 3V1M5A is specified for AC220V at 4.5 VA, one of five coil options in the 3V1 family, alongside AC110V, AC24V, DC24V and DC12V. Then check flow honestly - no Cv is published for the 3V1, so send us the application if flow matters. Need more? Move up to the 3V2 (1/8 and 1/4 ports, NC or NO selectable, Cv 0.18-0.19, vacuum rated) or the 3V3 (1/4 port, Cv 0.62), or to the 3V2M when manifold density outranks flow. Double-acting cylinders need the 5-port 4V series instead.
The five-point match: port (M5 or 1/8), thread (PT standard; G or NPT as order options), coil voltage, electrical entry (DIN plug as here, or flying lead), and individual versus manifold mounting in 1 to 20 stations.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V1 Solenoid Valve 3V1M5A FAQ
Pressure range 0-0.8 MPa, media temperature -20 to 70 C, and IP65 (DIN 40050) protection. This variant carries the AC220V 4.5 VA coil; family alternatives are AC110V 4.5 VA, AC24V 5.0 VA, DC24V 3.0 W and DC12V 2.5 W. There is no published Cv for the 3V1, so discuss demanding flow duties with us.
The 4.5 VA coil suits standard control-cabinet mains supplies without extra power electronics, and the DIN connector lets maintenance staff unplug the valve for service without touching the wiring. If your panel is low-voltage, the same M5 body exists with DC24V at 3.0 W or DC12V at 2.5 W.
