Airtac 3V1 Solenoid Valve 3V1M5B
The AirTAC Airtac 3V1 Solenoid Valve 3V1M5B is a genuine 3-port 2-position (3/2) solenoid valve with M5 ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Port sizeM5
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V1
About the Airtac 3V1 Solenoid Valve 3V1M5B
The 3V1M5B is the low-voltage, plug-in member of the 3V1 family: a direct-acting 3/2 solenoid on M5 ports whose DC24V coil draws only 3.0 W, among the lowest power draws in the range. It feeds or vents a single line, which covers single-acting cylinders, air blow, clamps and pilot signals.
Spring return resets the spool whenever 24 V is removed, and the DIN plug connection lets an electrician unplug the coil without touching the wiring. Protection is IP65 (DIN 40050), and the initial state is fixed at one setting - verify it on the datasheet before relying on it in a safety path.
Airtac 3V1 Solenoid Valve 3V1M5B Technical Specifications
| Model | Airtac 3V1 Solenoid Valve 3V1M5B |
|---|---|
| Series | 3V1 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Port size | M5 |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 3.0 W |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Not published for 3V1 |
| Temperature | -20 to 70 C |
| Construction | Direct-acting, single solenoid, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V1 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V1 Solenoid Valve 3V1M5B
| 3V1 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| M5 | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V1 Solenoid Valve 3V1M5B Is Used
24 V output on a CNC tool setter
A CNC's 24 V PLC output drives the 3.0 W coil to vent a spring-return probe clamp, keeping the machine's DC power budget effectively untouched.
Service-truck clamp control
Mobile service vehicles run a small work clamp from the truck's 24 V system, with the DIN plug allowing a quick coil swap at the roadside without rewiring.
Intermittent blow-off on a digital press
A digital press clears toner dust from a guide roller with short DC24V air pulses through an M5 nozzle, venting the line to exhaust between shots.
Is the Airtac 3V1 Solenoid Valve 3V1M5B the Right Part?
With a 3.0 W DC24V coil, this body suits battery-backed supplies and 24 V PLC outputs where every watt counts; it is also the smallest, lowest-power body in AirTAC's 3V line-up. Because no Cv is published for 3V1, confirm flow-critical sizing with us; step up to 3V2 (1/8 and 1/4 ports, NC or NO selectable, Cv 0.18-0.19, vacuum rated) or 3V3 (1/4 port, Cv 0.62) for more flow, and to 3V2M when manifold density beats flow. Double-acting cylinders need the 5-port 4V series.
Check five points before ordering: port (M5 here; 1/8 also offered), thread on 1/8 variants (PT is the standard specification; G or NPT are options to order - M5 carries no thread code), coil voltage, electrical entry (DIN plug here, flying lead as the alternative), and individual valve versus manifold station count (this code is an individual valve).
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V1 Solenoid Valve 3V1M5B FAQ
Pressure 0-0.8 MPa (0-114 psi); temperature -20 to 70 C; DC24V coil 3.0 W (other 3V1 coils: DC12V 2.5 W, AC24V 5.0 VA, AC110V 4.5 VA, AC220V 4.5 VA); protection IP65 (DIN 40050); air filtered to 40 um or finer; direct-acting 3/2 with spring return and manual override. Cv and effective area are not published for the 3V1 body, so confirm flow duties with us.
Choose this version when the valve hangs off a 24 V PLC output or a battery-backed supply: at 3.0 W the coil is easy on the supply and safe to switch from a small relay, and the DIN plug lets the coil be unplugged for testing. If your panel is AC, the A, C and E codes cover AC220V, AC110V and AC24V instead.
