AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryFlying lead (lead-out wire type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3)
AirTAC 3V11006NCAI-X3 is a 3/2 solenoid valve: three ports (supply, outlet, exhaust) and two states, feed or vent. Normally closed, it holds the outlet vented until the AC220V coil is switched on, which is exactly what a spring-return clamp or a blow-off line wants between cycles. The PT 1/8" port takes standard PT fittings and tubing.
Its coil is wired by flying lead (lead-out wire), so no separate DIN connector has to be ordered. This is a genuine AirTAC part from the 3V1 series; the same body is offered normally open, in five coil voltages, with DIN-plug entry, and on 3V1 manifold bases that carry several valves on one shared supply. Datasheet figures for pressure, flow and coil power are not on this page - ask us and we will confirm them for your operating conditions.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | Flying lead (lead-out wire type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| I | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3) Is Used
Parts ejector on an assembly stamper
Finished parts are nudged off the die by a spring-return ejector cylinder that is fed only while the coil is energised.
Workshop blow-off gun actuation
A foot-switched or solenoid-switched air line clears swarf from bench fixtures, dead and vented whenever the coil is off.
Sample rinse valve on a lab washer
The valve opens a rinse-air purge to the wash chamber for a fixed cycle and vents the line the moment the cycle ends.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3) the Right Part?
This listing is for a single 3V1 valve with flying-lead wiring; the alternative is DIN-plug entry, which uses a detachable connector that can be swapped without touching the machine wiring. The AC220V coil is fixed - match it to a 220 V AC supply, since coil voltage cannot be converted in the field. Normally closed suits a clamp or spray line that must go dead when the coil drops out; normally open exists if you need the reverse. The PT 1/8" port fits small spring-return cylinders; step to 1/4" or 3/8" for bigger ones, or group valves on a shared-feed manifold base with the valves ordered separately. We cannot quote flow for this family, so send us the actuator details and we will confirm sizing from the datasheet. Buyers who need published flow and coil power straight away can look at the documented AirTAC 3V2 and 3V3 bodies, and anyone driving a double-acting cylinder needs the 5-port 4V series instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCAI-X3) FAQ
Flying lead (the I in 3V11006NCAI-X3) wires the coil directly into a junction box or terminal strip and needs no separate connector. The DIN-plug versions of this body take a detachable connector, which is handy when a coil may need replacing at the machine. Both entries exist across the 3V1 family.
Yes. We do not list pressure, flow or coil-power figures for this series, so send your supply pressure and actuator details and we will return the datasheet values. If you want figures that are already published, the documented AirTAC 3V2 (1/8" and 1/4") and 3V3 (1/4") bodies are the alternative.
