AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM)
A 3/2 solenoid valve has three ports - supply, outlet and exhaust - and two states: it either feeds air to the outlet or vents the outlet to exhaust. On this 3V11006NCB-AM the state is normally closed, so the outlet receives no air until the DC24V coil is energised, and when power is lost the outlet vents instead. That makes it a natural choice wherever air must be removed from a circuit on power failure.
This is a genuine AirTAC part from the 3V1 family, in a 1/8in PT port size. The same family is available in both normally closed and normally open states, five coil voltages, DIN plug or flying-lead entry, plus 3V-F manifold bases. Pressure, flow and coil power are not published on this page; send us the reference and we will return the datasheet figures for you.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM) Is Used
Drill jig clamping
Release the clamp on a small drill jig the moment the machine stops, since an NC valve vents the single-acting cylinder when coil power is lost.
Swarf blow-off
Switch a compressed-air nozzle on a bench lathe to clear chips from the cutting zone between passes.
Lab rig actuation
Drive a small spring-return test cylinder on a laboratory fixture wired to a 24V DC panel supply.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM) the Right Part?
Normally closed suits circuits that must shut off air when control power drops; choose normally open if the opposite fail-safe is required. A 1/8in port is the small end of the range and pairs best with compact single-acting actuators or blow duties; move up to 1/4in or 3/8in for larger cylinders. The coil voltage is fixed at order time - DC24V here - and cannot be changed by rewiring, so match it to your panel supply.
Because flow figures for this family are not in our hands, ask us to size the valve against your actuator before ordering. If you need published flow and coil-power numbers today, the AirTAC 3V2 and 3V3 bodies carry them; for a double-acting cylinder you need a 5-port valve from the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-AM) FAQ
We do not publish numbers for the 3V1 family that we cannot stand behind, so we read operating pressure, flow and coil draw from the AirTAC datasheet and confirm them when you send an RFQ. If you need published figures immediately, the AirTAC 3V2 and 3V3 bodies document them.
No. A 3/2 valve has only one outlet, so it can feed and vent a single-acting, spring-return cylinder or an air blow line, but a double-acting cylinder needs both directions piped - use a 5-port AirTAC 4V valve for that.
