AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryFlying lead (lead-out wire type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI)
The 3V11006NCBI is a 3-port, 2-position solenoid valve in AirTAC's 3V110 body. With three ports (supply, outlet, exhaust) and two states, its job is simple and vital: it either feeds air to your outlet or vents that outlet to exhaust. The NC in the code means normally closed - with the coil de-energised, no air reaches the outlet, so a connected single-acting cylinder stays retracted and a blow line stays dead until you switch it on. The 1/8in port and PT thread make this the compact end of the family, and the DC24V coil arrives with flying leads already attached, ready to wire straight into your loom without a separate plug.
We stock the 3V11006NCBI as a genuine AirTAC part and ship it as such. Alongside it sits the rest of this family: normally open as well as normally closed, five coil voltages, DIN plug and flying-lead entries, and 3V-F manifold bases for multi-valve installations. Published figures for pressure, flow and coil power are not in our hands for this series, so send us your requirement and we will confirm them from the datasheet on request.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | Flying lead (lead-out wire type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| I | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI) Is Used
Single-acting clamp cylinder on a fixture
A spring-return clamping cylinder on a machining or welding fixture stays open while the machine is idle and clamps only when the 3V11006NCBI is energised - if control power drops, the NC valve stops feeding and the spring retracts the clamp.
Targeted air blow-off between cycles
On a packaging or filling line, a 1/8in outlet is well matched to a small nozzle or air knife that clears dust and splashes from a container mouth or sensor eye exactly when the cycle calls for it, and vents cleanly when it does not.
Lab and test-rig air switching
Bench rigs and test stations built around 24V DC control use the flying-lead coil to switch a small air feed, a sample ejector or a suction cup from a PLC output, with the exhaust port giving a visible, audible vent when the valve releases.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI) the Right Part?
Start with the fail-safe question. If the outlet must stay unpressurised when power is lost, the NC version - this valve - is correct: de-energised, the outlet vents rather than feeds. If instead your actuator must hold or release on power failure, ask us for the NO variant in the same body. Next, the port: 1/8in is the smallest threaded option here (M5 aside), best matched to small single-acting cylinders, compact blow lines and pilot-duty tasks; step up to the 1/4in and 3/8in bodies in this family when the actuation volume grows. The coil is fixed at DC24V - solenoid coils are wound for one voltage, so this SKU suits a 24V DC panel and rewiring will not change that. Flying leads come pre-wired; choose a DIN plug variant if your panels standardise on plug-in coils. One caution: a 3/2 valve cannot drive a double-acting cylinder, which needs pressurised air on both strokes - that need calls for the AirTAC 4V series. Because we cannot quote a flow figure for this family here, ask us to check sizing against your actuator before ordering; and if you need published performance numbers today, the AirTAC 3V2 and 3V3 bodies carry documented flow and coil-power figures and are the better-supported route.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCBI) FAQ
We do not hold a published datasheet for this family, so those numbers do not appear on this page. Send us an RFQ and we will confirm pressure range, flow and coil power from the manufacturer documentation. If you need figures published on the page itself today, the AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) bodies have documented specifications and are stocked as well.
No - a 3/2 valve has one outlet and one exhaust, so it cannot pressurise both ports of a double-acting cylinder. For that, use an AirTAC 4V 5-port valve. And because this is the NC version, it fails closed: power loss means the outlet vents and no air is supplied. If your safety case needs the opposite, ask us for the NO variant of the same body.
