AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM)
Every 3/2 valve does one job with three ports and two positions: it connects supply to outlet, or it dumps the outlet to exhaust. The 3V11006NCD-AM is the normally closed 1/8in PT version of that job - no air at the outlet until the coil is energised, then feed, and back to vent on de-energising. That is what a spring-return cylinder or a blow line needs.
This is a genuine AirTAC part. The coil variant for this code is not stated on the page, so confirm it with us rather than guess; the RFQ covers that along with the pressure and flow figures we do not quote here. The wider 3V1 family spans both states, five voltages, both electrical entries and 3V-F manifold bases.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | Confirm from the datasheet — ask us |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
This code carries a coil option we do not have documented. Ask us and we will confirm the voltage against the factory label before you order.
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM) Is Used
Workholding clamp on a welding fixture
A spring-advance clamp on a weld fixture that must release before the cell opens its guard; the NC outlet stays vented until the controller energises the coil.
Pneumatic gate on a bagging line
Drives a single-acting flap gate that lets product into a bagging hopper for one part of the cycle, then dumps the gate's air on the return stroke.
Guard-circuit vent
Vents a spring-release clamp in a guarding circuit so the actuator only grips while the safety controller holds the coil energised.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM) the Right Part?
Because one segment of this code is not decodable here, treat the coil variant as open until we confirm it - tell us your panel supply (the family runs AC220V, AC110V, DC24V, AC24V and DC12V) and we will verify the part before you commit. What is certain: normally closed behaviour on a 1/8in PT port (G and NPT exist as catalogue options), feeding and venting a single-acting actuator. If your cylinder is double-acting, this 3/2 valve is the wrong tool - the 5-port AirTAC 4V series is built for it. Prefer a larger port? The same body comes in 1/4in (08) and 3/8in (10), and M5 below; DIN plug and flying lead both exist, as do 3V-F manifold bases for multi-valve panels. We quote no flow figure for the 3V1 family on this page, so have us check the datasheet against your actuator - or choose the documented 3V2 and 3V3 bodies, which publish flow and coil power.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCD-AM) FAQ
The trailing segment of this code is not one we decode on this page, so we leave the voltage blank rather than guess. Tell us your panel supply in the RFQ and we will verify the exact coil from the AirTAC datasheet. Pressure and flow figures are confirmed the same way.
Yes. The 3V1 family has 3V-F manifold bases that carry several valves on one shared air supply and one wiring loom, which makes fault-finding simpler; valves are ordered separately. For a single-acting actuator, this individual valve is the normal choice.
