Airtac 3V2 Solenoid Valve 3V206NOB
The AirTAC Airtac 3V2 Solenoid Valve 3V206NOB is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally open
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Flow (Cv)0.18
- Series3V2
About the Airtac 3V2 Solenoid Valve 3V206NOB
The AirTAC 3V206NOB is a normally open 3/2-way direct-acting solenoid valve: supply air flows to the outlet as soon as it is connected, and energising the DC24V coil shuts the path and vents the line. That behaviour suits circuits where a line must stay live until a controller actively interrupts it. The valve drives single-acting cylinders, air blow, clamps, vacuum switching and pilot signals - never a double-acting cylinder, which needs a 5-port 4V valve.
Inside is a coaxial poppet with a single solenoid and spring return, giving good sealing at high flow for a 1/8in body: 3.2 mm2 effective area, Cv 0.18 per port. The DC24V coil draws 7.0 W, and the body is rated for vacuum service down to -102.2 kPa - a capability the 3V1 and 3V2M bodies do not share.
Airtac 3V2 Solenoid Valve 3V206NOB Technical Specifications
| Model | Airtac 3V2 Solenoid Valve 3V206NOB |
|---|---|
| Series | 3V2 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally open |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7.0 W |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Rated -102.2 kPa to 0.1 MPa |
| Flow coefficient | Cv 0.18 (3.2 mm2 effective area) |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), direct-acting, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2 Solenoid Valve 3V206NOB
| 3V2 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NO | Normally open: air passes until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2 Solenoid Valve 3V206NOB Is Used
Swing clamp on a drilling fixture
A normally open valve keeps a single-acting swing clamp on a drilling fixture pressurised until the PLC cuts the coil, releasing the part.
Bottle blow-off station
On a rinsing line, supply air passes to the nozzles continuously and the solenoid closes the path for the dry-off cycle between bottles.
Vacuum degassing bell jar
Rated to -102.2 kPa, the valve isolates the pump line from a small degassing bell jar without switching to a dedicated vacuum valve.
Is the Airtac 3V2 Solenoid Valve 3V206NOB the Right Part?
Step down to a 3V1 if the duty is small and coil power is the constraint - its DC24V coil draws 3.0 W against 7.0 W here. Choose the base-mounted 3V2M only when a dense multi-station manifold outweighs flow, because routing through the base cuts Cv to 0.1. When the job needs substantially more air, the 3V3 at 1/4in and Cv 0.62 (also vacuum-rated) is the sensible step up.
Before ordering, match five points: 1/8in port with PT thread as standard (G and NPT are order options), normally open initial state, DC24V coil, DIN plug entry, and whether the circuit includes vacuum. Need a double-acting cylinder moved? That is a job for the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2 Solenoid Valve 3V206NOB FAQ
The 3/2 valve has a 3.2 mm2 effective area and Cv 0.18 per port in the 1/8in size (the 1/4in 3V208 reaches 3.4 mm2 and Cv 0.19). Operating pressure is 0-0.8 MPa, with vacuum service rated from -102.2 kPa to 0.1 MPa. Media temperature spans -20 to 70 C, the DC24V coil draws 7.0 W (AC coils 7 VA), and protection is IP65 (DIN 40050).
A NO 3V2 feeds the outlet as soon as supply air arrives and only shuts when the coil is energised - useful where a line should default to flowing, such as blow, clamping hold or a pilot signal. A NC version does the opposite and stays vented until switched. Both states are order codes on the same 3V2 body.
