Airtac 3V2 Solenoid Valve 3V208NCA
The AirTAC Airtac 3V2 Solenoid Valve 3V208NCA is a genuine 3-port 2-position (3/2) solenoid valve with 1/4 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/4 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Flow (Cv)0.19
- Series3V2
About the Airtac 3V2 Solenoid Valve 3V208NCA
The AirTAC 3V208NCA is a 3/2-way direct-acting solenoid valve in the normally closed arrangement: with the coil de-energised the spring holds the coaxial poppet shut, so the 1/4in outlet stays vented until AC220V is applied. It feeds or vents a single line, which suits single-acting spring-return cylinders, clamps, air blow and pilot duty on a larger valve. Effective area is 3.4 mm2 (Cv 0.19) per port.
Coil draw is 7 VA on the AC220V winding, and the IP65 (DIN 40050) housing plus the DIN plug connector keep wiring to a snap-on job. A manual override is fitted for commissioning without power. Notably, the 3V2 body carries a vacuum rating of -102.2 kPa to 0.1 MPa, so the same valve can switch negative-pressure circuits that 3V1 and 3V2M cannot. Genuine AirTAC product is confirmed on every order.
Airtac 3V2 Solenoid Valve 3V208NCA Technical Specifications
| Model | Airtac 3V2 Solenoid Valve 3V208NCA |
|---|---|
| Series | 3V2 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Port size | 1/4 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Rated -102.2 kPa to 0.1 MPa |
| Flow coefficient | Cv 0.19 (3.4 mm2 effective area) |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), direct-acting, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2 Solenoid Valve 3V208NCA
| 3V2 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/4 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2 Solenoid Valve 3V208NCA Is Used
CNC milling vise clamping
Energising the coil pressurises the clamp cylinder on a machining fixture; de-energising vents the line so the spring retracts the vise after every cycle or power cut.
Vacuum hold-down on a CNC router
Switches vacuum to the cup grid holding MDF or acrylic sheets; rated to -102.2 kPa, it handles negative-pressure service that the 3V1 and 3V2M bodies are not built for.
Pilot stage on a packaging machine
Works as the small pilot valve commanding a larger 4V main valve on box-eject cylinders, giving the PLC one dry-contact point to switch the whole station.
Is the Airtac 3V2 Solenoid Valve 3V208NCA the Right Part?
Confirm five points before ordering: 1/4in port with PT thread (G and NPT are catalogue options), normally closed initial state, AC220V coil, DIN plug entry, and whether the duty includes vacuum - this body is rated for it. If the flow demand outgrows Cv 0.19, the real step is the 3V3 series at Cv 0.62 on 1/4in, also vacuum-rated; moving within 3V2 buys little because the Cv only shifts from 0.18 to 0.19 across the port sizes.
Scale down when it fits: the 3V1 handles light duties with a 3.0 W DC24V coil where the 3V2 DC versions draw 7.0 W, and the 3V2M trades individual ports for a dense multi-station manifold at Cv 0.1. A double-acting cylinder needs five ports - send that duty to the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2 Solenoid Valve 3V208NCA FAQ
Effective area is 3.4 mm2 (Cv 0.19) per port for the 1/4in 3V208 body; the 1/8in 3V206 gives 3.2 mm2 (Cv 0.18). Operating pressure is 0-0.8 MPa, with vacuum service rated -102.2 kPa to 0.1 MPa. Temperature range is -20 to 70 C. Coil power is 7 VA on AC and 7.0 W on DC versions, and protection is IP65 (DIN 40050).
It is a 3-port valve: it either feeds the outlet or vents it to exhaust. That covers single-acting spring-return cylinders, clamps, air blow, vacuum switching and pilot duty. It cannot drive a double-acting cylinder, which needs pressure to both sides - use the AirTAC 4V series there.
