Airtac 3V2 Solenoid Valve 3V208NCB
The AirTAC Airtac 3V2 Solenoid Valve 3V208NCB is a genuine 3-port 2-position (3/2) solenoid valve with 1/4 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/4 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Flow (Cv)0.19
- Series3V2
About the Airtac 3V2 Solenoid Valve 3V208NCB
3V208NCB is the DC24V member of the 3V2 family: a 3/2-way, direct-acting, single-solenoid valve with spring return and a coaxial poppet that seats cleanly for tight shutoff. Normally closed, it keeps the 1/4in outlet vented until the 7.0 W coil is energised from a 24 V supply - the same bus that powers most PLC and relay outputs, so no separate control transformer is needed.
Each port offers 3.4 mm2 effective area (Cv 0.19). The valve also switches vacuum circuits, rated -102.2 kPa to 0.1 MPa, something the 3V1 and 3V2M bodies cannot claim. IP65 (DIN 40050) protection and a manual override round out the package; source is genuine AirTAC.
Airtac 3V2 Solenoid Valve 3V208NCB Technical Specifications
| Model | Airtac 3V2 Solenoid Valve 3V208NCB |
|---|---|
| Series | 3V2 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Port size | 1/4 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7.0 W |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Rated -102.2 kPa to 0.1 MPa |
| Flow coefficient | Cv 0.19 (3.4 mm2 effective area) |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), direct-acting, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2 Solenoid Valve 3V208NCB
| 3V2 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/4 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2 Solenoid Valve 3V208NCB Is Used
PLC-driven leak-test bench
A 24 V DC output card energises the valve directly to pressurise a leak-test fixture; dropping the output vents the part, and the manual override helps fixture setup.
Solar laminate glass handling
Switches vacuum to suction cups lifting glass-faced laminates; the -102.2 kPa rating suits negative-pressure lines, with 24 V control shared straight from the machine PLC.
Electronics jig pin clamp
Extends a spring-return pin clamp on an assembly jig; on power loss the valve vents and the jig releases, so operators can always free the workpiece by hand.
Is the Airtac 3V2 Solenoid Valve 3V208NCB the Right Part?
Check the five match points: 1/4in port on PT thread (G and NPT are order options), normally closed state, DC24V coil, DIN plug entry, and any vacuum duty - covered here to -102.2 kPa. On 24 V control, remember the 3V1 DC coil runs at 3.0 W versus 7.0 W here if panel heat or power budget is tight.
Flow-wise, 3V208 sits at Cv 0.19 against 0.18 for the 1/8in 3V206, so a genuine jump in flow means moving to 3V3 (Cv 0.62, also vacuum-rated). Prefer manifold density over individual ports? The 3V2M gives Cv 0.1 per station. Double-acting cylinder in the spec? That is a 5-port job - route it to the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2 Solenoid Valve 3V208NCB FAQ
Per-port effective area is 3.4 mm2 and Cv is 0.19 on this 1/4in body (the 1/8in 3V206 is 3.2 mm2 / Cv 0.18). Operating pressure is 0-0.8 MPa; the vacuum rating is -102.2 kPa to 0.1 MPa. Temperature spans -20 to 70 C. Coil power is 7 VA on AC and 7.0 W on DC versions, with IP65 (DIN 40050) protection.
Yes - unlike 3V1 and 3V2M, the 3V2 body is rated for negative-pressure service from -102.2 kPa to 0.1 MPa, so it switches vacuum lines as well as the standard 0-0.8 MPa compressed-air range. No vacuum flow rate or pump-down time is published; confirm those from the datasheet or ask via RFQ before sizing the circuit.
