Airtac 3V2 Solenoid Valve 3V208NCE
The AirTAC Airtac 3V2 Solenoid Valve 3V208NCE is a genuine 3-port 2-position (3/2) solenoid valve with 1/4 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/4 in
- Coil voltageAC24V
- Electrical entryDIN plug (DIN socket type)
- Flow (Cv)0.19
- Series3V2
About the Airtac 3V2 Solenoid Valve 3V208NCE
At AC24V the 3V208NCE runs on the low control voltage many machine builders prefer for operator safety and standard safety-circuit outputs. It is a 3/2, normally closed valve with 1/4in PT ports: until the coil is powered the outlet is closed and vented, then it opens to feed the downstream line.
Direct-acting spring return with a coaxial shut-off poppet means no pilot air is needed to shift it. Each port passes Cv 0.19 (3.4 mm2 effective area). This body is also rated for vacuum service down to -102.2 kPa, unlike the smaller 3V1, so vacuum cups and pressure circuits can share the same valve type on one machine.
Airtac 3V2 Solenoid Valve 3V208NCE Technical Specifications
| Model | Airtac 3V2 Solenoid Valve 3V208NCE |
|---|---|
| Series | 3V2 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Port size | 1/4 in |
| Thread | PT |
| Coil voltage | AC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Rated -102.2 kPa to 0.1 MPa |
| Flow coefficient | Cv 0.19 (3.4 mm2 effective area) |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), direct-acting, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2 Solenoid Valve 3V208NCE
| 3V2 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/4 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2 Solenoid Valve 3V208NCE Is Used
Woodworking clamp actuation
The spring-return NC valve vents the clamp line whenever power is lost on the AC24V control circuit, a safe default around saws and presses.
Vacuum hold-down on a lab sample table
Rated to -102.2 kPa, it switches the negative-pressure line holding samples or masks, sharing a valve type with the pneumatic tooling beside it.
Stopper cylinder at a pallet conveyor junction
AC24V ties into machine safety circuits; energise to raise the stopper, and the exhaust port dumps the single-acting cylinder when released.
Is the Airtac 3V2 Solenoid Valve 3V208NCE the Right Part?
Confirm five things against your spec: 1/4in port with PT thread standard (G or NPT available to order), normally closed state, AC24V coil, DIN plug entry and any vacuum duty, for which this body is approved to -102.2 kPa. Down-sizing: pick 3V1 where only tiny flow and the lowest coil draw (3.0 W on DC24V) matter, or 3V2M when a manifold of closely packed stations beats the Cv 0.19 you get here. Up-sizing: the 3V3 delivers Cv 0.62 on 1/4in and still handles vacuum.
For double-acting cylinder control, move to the AirTAC 4V family.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2 Solenoid Valve 3V208NCE FAQ
1/4in PT port, 3.4 mm2 effective area and Cv 0.19 per port (the 1/8in 3V206 is 3.2 mm2 / Cv 0.18). Working pressure 0-0.8 MPa with a vacuum rating of -102.2 kPa to 0.1 MPa. Operating temperature -20 to 70 C. Coil power is 7 VA on AC (this model) and 7.0 W on DC. Enclosure protection IP65 (DIN 40050).
With the AC24V coil de-energised the outlet is blocked from supply and connected to exhaust, so the downstream single-acting cylinder or blow nozzle is deliberately vented at rest. Air only reaches the outlet while the coil is powered. Choose the NO variant instead if the line must pass air until the valve is told to stop it.
