Airtac 3V2 Solenoid Valve 3V208NCF
The AirTAC Airtac 3V2 Solenoid Valve 3V208NCF is a genuine 3-port 2-position (3/2) solenoid valve with 1/4 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/4 in
- Coil voltageDC12V
- Electrical entryDIN plug (DIN socket type)
- Flow (Cv)0.19
- Series3V2
About the Airtac 3V2 Solenoid Valve 3V208NCF
3V208NCF is the 12 V DC build of the AirTAC 3V2: a normally closed, direct-acting 3/2 poppet valve on a 1/4in PT port. De-energised, it holds the outlet vented and the supply shut off, so no air reaches the line until the coil is powered. Spring return resets it the instant power drops. The coaxial shut-off poppet gives a clean seat at a per-port flow of 3.4 mm2 effective area, Cv 0.19.
The 7.0 W DC coil suits battery carts, mobile equipment and other sites where no 24 V or AC supply exists, and the DIN plug accepts a standard square connector. This body carries a vacuum rating of -102.2 kPa to 0.1 MPa, so the same valve can switch negative-pressure circuits too. Medium is air filtered to 40 um or finer; lubrication is not required.
Airtac 3V2 Solenoid Valve 3V208NCF Technical Specifications
| Model | Airtac 3V2 Solenoid Valve 3V208NCF |
|---|---|
| Series | 3V2 |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Port size | 1/4 in |
| Thread | PT |
| Coil voltage | DC12V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7.0 W |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Rated -102.2 kPa to 0.1 MPa |
| Flow coefficient | Cv 0.19 (3.4 mm2 effective area) |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), direct-acting, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2 catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2 Solenoid Valve 3V208NCF
| 3V2 | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/4 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC12V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2 Solenoid Valve 3V208NCF Is Used
Battery-powered material handling
A 12 V lead-acid supply on an electric pallet-truck or utility cart runs the coil directly, so the valve can switch a spring-return clamp or blow line without an inverter.
Blow-off on a small parts feeder
Energise to open the supply to a 1/4in air nozzle that clears chips or dust from a fixture; de-energise and the NC poppet leaves the line dead and vented.
Vacuum hold-down on a bench-top router
Rated from -102.2 kPa to 0.1 MPa, the valve can isolate a vacuum chuck gripping plywood or acrylic, releasing the workpiece with the manual override during setup.
Is the Airtac 3V2 Solenoid Valve 3V208NCF the Right Part?
Flow here is the per-port figure: Cv 0.19 (3.4 mm2) on this 1/4in body. Step down to 3V1 when the duty is small and every watt counts (its DC24V coil draws 3.0 W against 7.0 W here), or to 3V2M when a dense multi-station base matters more than flow (Cv 0.1 through the manifold). If the job genuinely needs more air, move up to 3V3: 1/4in, Cv 0.62 and also vacuum-rated. Confirm five points before ordering: port size and thread (1/8in or 1/4in; PT is the standard thread on this family, G and NPT are order options), initial state NC or NO, coil voltage, electrical entry (DIN plug or flying lead), and whether the duty involves vacuum. A double-acting cylinder needs a 5-port valve - go to the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2 Solenoid Valve 3V208NCF FAQ
This 1/4in port (3V208) flows 3.4 mm2 effective area, Cv 0.19 per port; the 1/8in 3V206 body is 3.2 mm2, Cv 0.18. Pressure range is 0-0.8 MPa, with vacuum service rated -102.2 kPa to 0.1 MPa. Temperature spans -20 to 70 C. Coils draw 7 VA on AC and 7.0 W on DC, and the housing meets IP65 (DIN 40050).
No. A 3/2 valve has three ports - supply, outlet, exhaust - and only ever feeds or vents one line, which suits single-acting spring-return cylinders, blow duty, clamps, vacuum switching and pilot stages. For a double-acting cylinder you need a 5-port valve from the AirTAC 4V series.
