Airtac 3V2M-F Base 3V2M11F
The AirTAC Airtac 3V2M-F Base 3V2M11F is a genuine 3V2M manifold base for 11 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations11
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M11F
The 3V2M11F is the eleven-station version of the AirTAC 3V2M manifold base. It is a machined block only: no coil, no solenoid, no initial state and no IP rating sit in the base itself. It sets the station count at 11, feeds one shared air supply to every position and vents all stations through a single centralised exhaust port. The 3V2M valve bodies that plug into it are ordered separately, each with its own NC/NO state, coil voltage and electrical entry chosen at purchase.
Because supply and wiring are shared, a fault can be traced at the manifold instead of across eleven scattered valves, and stations can be mixed freely - NC and NO bodies side by side. Eleven DC coils drawing 7.0 W each give a worst-case 77 W, about 3.2 A at 24 V, when every station is energised at once, so size the supply for that figure.
Airtac 3V2M-F Base 3V2M11F Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M11F |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 11 |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M11F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 11F | 11 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M11F Is Used
Packaging machine carton clamps
Eleven spring-return clamp cylinders on a carton-closing machine can each hold a 3V2M valve on this base, sharing one supply and one exhaust line.
Textile machine solenoid bank
A weaving or knitting machine with eleven air-jet or tensioner valves wires back to one manifold, cutting the loom harness down to a single entry.
Fixture clamping on a CNC tombstone
An 11-position tombstone fixture uses one 3V2M valve per clamp face, all fed from this block so a dropped station is found at the manifold, not across the cell.
Is the Airtac 3V2M-F Base 3V2M11F the Right Part?
Pick this base when eleven valve positions are needed and a single exhaust line is acceptable. The valve bodies fitted above it are Cv 0.1 - the flow path runs through the base, so manifold density trades against flow. If one station must move more air, mount an individual 3V2 there (Cv 0.18 at 1/8 inch, 0.19 at 1/4 inch, vacuum-rated) or step that circuit to a 3V3 (Cv 0.62, 1/4 inch, vacuum-rated); 3V1 covers low-power duty at 3.0 W DC. Double-acting cylinders need a 5-port 4V valve, not a 3V2M circuit.
When ordering the valves, fix the initial state first - NC or NO cannot be converted after purchase, and flipping the dedicated base gasket does not change it. Then set coil voltage (A/B/C/E/F), entry (DIN plug or I flying lead) and thread: PT is the standard thread on this family, with G and NPT as catalogue options to order.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M11F FAQ
The base itself is unpowered; the 3V2M valves mounted on it are 3/2 direct-acting, Cv 0.1, operating pressure 0-0.8 MPa (0-114 psi), temperature -20 to 70 C, coil power AC 7 VA / DC 7.0 W, protection IP65 (DIN 40050). Ports are PT1/8; air must be filtered through a 40 um or finer element.
Nothing by itself. It is a manifold block that sets 11 stations, routes one shared supply and one centralised exhaust. Every NC/NO state, voltage and entry choice belongs to the valve bodies ordered separately, and NC/NO cannot be changed later by flipping the base gasket - it must be right at order time.
