Airtac 3V2M-F Base 3V2M13F
The AirTAC Airtac 3V2M-F Base 3V2M13F is a genuine 3V2M manifold base for 13 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations13
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M13F
Thirteen 3/2 valves, one air inlet, one exhaust line - that is what the 3V2M13F block delivers. As a manifold base it contains no coil, solenoid, voltage or initial state, and it carries no IP rating; those are properties of the 3V2M valve bodies ordered separately and seated onto it. Thirteen stations share a unified supply, and all exhaust air leaves through a single centralised port.
Single-point exhaust simplifies piping and silencing in compact cabinets, and the unified supply means stations can be added, mixed or swapped without replumbing the whole machine. Keep the density trade-off in mind: because every flow path passes through the block, each valve position is Cv 0.1 rather than the higher figure of a free-standing 3V2.
Airtac 3V2M-F Base 3V2M13F Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M13F |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 13 |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M13F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 13F | 13 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M13F Is Used
Sorting diverters on a parcel line
Thirteen divert or stopper cylinders along a parcel-sorting conveyor each take a valve position on this base, sharing one exhaust run above the line.
Press tool part ejectors
A stamping die with thirteen spring-return ejector or knockout pins can fire each from its own 3V2M valve seated on this one block.
Dosing valves on a filling carousel
Thirteen micro-dosing or purge valves around a rotary filler are plumbed to a unified supply, so tuning and venting happen at one centralised port.
Is the Airtac 3V2M-F Base 3V2M13F the Right Part?
Choose the 3V2M13F when thirteen valve positions are wanted on one block and a common exhaust line is fine. Size each circuit first: Cv 0.1 per valve suits clamping, blow-off and pilot duty. A station that must breathe harder is better served by an individual 3V2 (Cv 0.18 at 1/8 inch, 0.19 at 1/4 inch, vacuum-rated) or a 3V3 (Cv 0.62, 1/4 inch, vacuum-rated), while light-duty points can drop to 3V1 at 3.0 W DC. Thirteen DC coils at 7.0 W give a 91 W worst case, about 3.8 A at 24 V - check your supply.
Valves are ordered separately, so lock in NC or NO before purchase; it cannot be converted afterwards, and flipping the dedicated base gasket achieves nothing. Then set voltage (A/B/C/E/F), entry (DIN plug or I flying lead) and thread (PT standard; G and NPT to order). A double-acting cylinder needs the 5-port 4V series instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M13F FAQ
Mounted 3V2M valves are 3/2, direct-acting, single solenoid with spring return: Cv 0.1, 0-0.8 MPa (0-114 psi), -20 to 70 C, AC 7 VA / DC 7.0 W per coil, IP65 (DIN 40050), PT1/8 ports, air filtered to 40 um or finer, manual override fitted. The base block itself has no electrical rating.
Yes - station positions mix freely, so NC and NO bodies, different voltages and either DIN plug or flying-lead entries can share one 3V2M13F. Just fix each valve's state when ordering: NC and NO cannot be converted after purchase, and the base gasket cannot be flipped to swap it.
