Airtac 3V2M-F Base 3V2M2F
The AirTAC Airtac 3V2M-F Base 3V2M2F is a genuine 3V2M manifold base for 2 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations2
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M2F
The 3V2M2F gives a two-station manifold block for AirTAC 3V2M valves - the compact choice where a machine needs just two 3/2 functions. It is a machined base only: no coil, no solenoid, no NC or NO state and no IP rating. One shared supply feeds both valve positions, and both stations vent through a single centralised exhaust.
With supply and wiring already routed through the block, replacing either valve later is a plug-and-gasket job rather than a re-pipe, and the block pairs with further 3V2M bases as the machine grows. Both valves are ordered separately.
Airtac 3V2M-F Base 3V2M2F Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M2F |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 2 |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M2F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 2F | 2 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M2F Is Used
Welding fixture clamps
Two spring-return swing clamps on a weld jig take one shared feed through the compact block.
Press setup functions
A stamping press setup mode runs one die clamp and one blow function from the two manifold stations.
Dock door interlock
Two locking cylinders on a warehouse dock door are fed and vented through the single centralised exhaust.
Is the Airtac 3V2M-F Base 3V2M2F the Right Part?
For the two valves on this base, match: NC or NO state per position, coil voltage, DIN plug or flying-lead entry, the 2-station count, and centralised exhaust. PT thread is the family standard; G and NPT are order options.
A valve sitting on this base flows Cv 0.1. If either station needs more, an individual 3V2 gives Cv 0.18 at 1/8" or 0.19 at 1/4" (vacuum-rated), and a 3V3 reaches Cv 0.62 at 1/4". For light duties the 3V1 runs at just 3.0 W DC. Double-acting cylinders need the 5-port AirTAC 4V series. NC and NO are decided at ordering and cannot be converted afterwards.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M2F FAQ
Each mounted 3/2 valve: Cv 0.1, operating pressure 0-0.8 MPa (0-114 psi), media temperature -20 to 70 C, protection IP65 (DIN 40050), coil power 7 VA on AC or 7.0 W on DC. The 3V2M2F block itself carries no electrical rating - those belong to the valves.
You get one shared supply and shared wiring for both stations, with a single centralised exhaust instead of two pipes. What is fixed: each valve's NC or NO state, chosen at order time, cannot be converted afterwards - the dedicated base gasket does not reverse the state.
