Airtac 3V2M-F Base 3V2M2FD
The AirTAC Airtac 3V2M-F Base 3V2M2FD is a genuine 3V2M manifold base for 2 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations2
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M2FD
The 3V2M2FD is the two-station version of the AirTAC 3V2M manifold range with independent exhaust. Each seated valve vents through its own dedicated exhaust port, so two functions can dump air at separate points on the machine instead of teeing into one shared outlet. One supply line feeds both stations, and the valves sit on a common wiring run.
This code is the machined base block only - there is no coil attached, so it has no voltage, no power draw and no NC/NO state of its own. Order the 3V2M valve bodies separately and specify NC or NO, the coil voltage and the electrical entry for each one; the base simply fixes the station count and the exhaust routing. Air enters at PT1/8 and the assembly works at 0-0.8 MPa between -20 and 70 C.
Airtac 3V2M-F Base 3V2M2FD Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M2FD |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 2 |
| Exhaust | Independent exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M2FD
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 2F | 2 stations in one assembly, independent exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M2FD Is Used
Two-function bench press fixture
Carries the clamp and eject valves of a small pneumatic press fixture on one block, with independent exhaust so the clamp dumps air away from the eject side of the tooling.
Paint booth blow-off pair
Two blow-off nozzles on a coating line run from one shared supply, while separate exhaust ports let each gun vent without blasting the neighbouring station.
Weld-cell swing clamps
A pair of swing clamps on a robot weld table can share this base, with each station exhausting at its own point so chips and spatter are not blown between clamps.
Is the Airtac 3V2M-F Base 3V2M2FD the Right Part?
Pick this base when you need exactly two 3/2 valves grouped together and want each station to vent on its own. The valves it carries are Cv 0.1 coaxial poppet units, so for any station needing more flow step up to a stand-alone 3V2 (Cv 0.18 at 1/8 in, Cv 0.19 at 1/4 in, and vacuum-rated) or 3V3 (Cv 0.62, 1/4 in, also vacuum-rated); if the duty is light and power is the constraint, 3V1 at 3.0 W DC is the leaner choice. A double-acting cylinder is out of scope for a 3-port valve - specify the AirTAC 4V series instead.
Decide five points before ordering: the initial state of each valve (NC or NO - it cannot be converted after purchase, and flipping the base gasket does not change it), the coil voltage, the electrical entry (DIN plug or flying lead I), the exhaust arrangement, and the thread. PT is standard on this family, with G and NPT available as order options.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M2FD FAQ
It is a 2-station 3V2M manifold base with independent exhaust, a PT1/8 port, a working range of 0-0.8 MPa and a temperature span of -20 to 70 C. The valves seated on it are Cv 0.1 direct-acting 3/2 units; coil power (AC 7 VA or DC 7.0 W) and the IP65 (DIN 40050) rating belong to the valves, not to the base itself.
On the valves. The block carries no initial state of its own - each 3V2M body you order onto it is specified as NC (closed until energised) or NO (open until energised) at purchase. The dedicated base gasket cannot be flipped to convert a valve afterwards, so order the right state up front. These 3/2 valves drive single-acting cylinders, not double-acting ones.
