Airtac 3V2M-F Base 3V2M6F
The AirTAC Airtac 3V2M-F Base 3V2M6F is a genuine 3V2M manifold base for 6 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations6
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M6F
Six circuits from one air connection: the 3V2M6F extends the 3V2M manifold concept to six valve positions on a single machined block. One PT1/8 inlet pressurises every station, and all six valves release their exhaust through a common central port, keeping the machine's pneumatic footprint to a single supply line and a single vent line.
As with every 3V2M base, there is no solenoid, coil or IP rating in the block itself - those properties come from the six valves, which you select and order separately. One shared wiring trunk across the stations also speeds up commissioning and later fault-finding.
Airtac 3V2M-F Base 3V2M6F Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M6F |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 6 |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M6F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 6F | 6 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M6F Is Used
Gripper bar on a carton-former
Six vacuum-free grip and release points on a carton erecting machine can each run a 3V2M valve from this one block, with supply and exhaust plumbed once.
Spray-gun actuator panel in a paint booth
Automated spray guns that tilt or trigger pneumatically take one valve per gun here, all venting through the single central exhaust away from the work area.
Guard interlock release circuits
Spring-return interlock or lock-out actuators on six machine guards can share one manifold supply, so a whole panel of safety positions is fed and wired uniformly.
Is the Airtac 3V2M-F Base 3V2M6F the Right Part?
Build your order around five decisions: NC or NO per valve (final at purchase), coil voltage, DIN plug or flying-lead entry, thread, and exhaust style. PT is the standard thread on the 3V2M family; G and NPT are options you can specify.
Six DC coils at 7.0 W add up to a 42 W worst-case draw when all stations energise together, so check your 24 V supply headroom. For circuits needing more than Cv 0.1, mount fewer valves on the base and add individual 3V2 bodies (Cv 0.18 at 1/8 in, vacuum-rated) or a 3V3 (Cv 0.62, 1/4 in); the 3V1 at 3.0 W DC is the economical choice for small loads. Double-acting cylinders call for the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M6F FAQ
The base provides six stations on one PT1/8 supply with a centralised exhaust. Each valve fitted to it is a 3/2 direct-acting unit rated 0-0.8 MPa, -20 to 70 C, Cv 0.1, coil power 7 VA on AC or 7.0 W on DC, protection class IP65. The manifold block alone carries none of these electrical or sealing ratings.
Each 3/2 valve has three ports - supply, outlet, exhaust - and two states, so it feeds or vents its outlet. That suits single-acting spring-return cylinders, air blow, clamping and pilot duty. It cannot drive a double-acting cylinder, which needs a 5-port valve such as the AirTAC 4V series. Valve NC/NO states cannot be converted after purchase.
