Airtac 3V2M-F Base 3V2M8FD
The AirTAC Airtac 3V2M-F Base 3V2M8FD is a genuine 3V2M manifold base for 8 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations8
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M8FD
Eight stations, eight separate exhausts. The 3V2M8FD is the independent-exhaust version of the eight-station 3V2M base: each valve vents through its own port, which isolates the exhaust of one station from another and makes later machine revisions easier, since functions can be added or removed without touching a shared vent line.
The block itself is passive - a machined manifold with no solenoid, no voltage and no IP rating, because those belong to the valve bodies mounted on it. Order the 3V2M valves separately, in any NC/NO and voltage mix, and share one air supply and one wiring run across the assembly. PT is the standard thread; G and NPT are order options.
Airtac 3V2M-F Base 3V2M8FD Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M8FD |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 8 |
| Exhaust | Independent exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M8FD
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 8F | 8 stations in one assembly, independent exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M8FD Is Used
Test bench fixture logic
An electronics end-of-line bench toggles eight clamps and blow-offs; per-station exhausts make it obvious which function vented on each cycle.
Modular welding jigs
A sheet-metal shop reconfigures welding jigs often; up to eight toggle clamps sit on the block and stations are re-mixed without new plumbing.
Glue-head shut-off bank
A corrugated case line opens and closes eight glue-head air gates from one block, and each station's exhaust is piped away from the electronics cabinet.
Is the Airtac 3V2M-F Base 3V2M8FD the Right Part?
This base makes sense when station exhausts must be piped or silenced apart - for example near sensitive electronics or inside an enclosed frame. Count the functions you need now and leave spare positions if the machine will grow, since 3V2M stations mix and expand freely. Specify thread (PT standard; G and NPT to order) and then order the eight valve bodies separately, fixing NC or NO, coil voltage and DIN plug or flying lead entry on each; the initial state cannot be changed after purchase.
Mounted valves flow Cv 0.1, so for a duty needing more, use a standalone 3V2 (Cv 0.18 at 1/8 in, Cv 0.19 at 1/4 in, vacuum-rated) or 3V3 (Cv 0.62 at 1/4 in), or drop to 3V1 at 3.0 W DC for low-power duties. Double-acting cylinders require the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M8FD FAQ
The block is passive; the valves define the figures: Cv 0.1, 0-0.8 MPa, -20 to 70 C, IP65 (DIN 40050), AC coils 7 VA, DC coils 7.0 W, air filtered to 40 um or finer. Manual override on each valve helps commissioning. Note the 3V2M family has no vacuum rating.
3V2M stations combine and expand freely, and NC, NO and voltage types can be mixed on one block, so adding or freeing a position is a valve-order change, not new plumbing. Exhausts stay independent per station. Order valves with the correct initial state up front - NC cannot be converted to NO after purchase.
