Airtac 3V2M Solenoid Valve 3V2MNCA
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA Solenoid Valve Technical Specifications
- Model: 3V2MNCA
- Valve type: 3-way, 2-position normally closed (Pilot-operated)
- Port configuration: 3 ports (P: Pressure, A: Output, R: Exhaust)
- Port thread size: 1/8" BSPP (G1/8) standard, M5 optional
- Operating pressure range: 0.1-0.8 MPa (14.5-116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Maximum flow rate: 700 L/min (ANR) at 0.5 MPa
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Ambient temperature range: -20℃ to +70℃ (with no freezing)
- Fluid temperature range: 0℃ to +60℃
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 1.5W (DC), 2.5VA (AC)
- Protection rating: IP67 (Dustproof/water immersion resistant)
- Body material: Reinforced PBT with copper solenoid components
- Weight: 210g ±5% (without connector)
- Dimensions: 40mm (L) × 25mm (W) × 55mm (H)
- Mounting orientation: Any (Horizontal recommended for optimal drainage)
High-performance compact solenoid valve featuring rapid switching capability and energy-efficient design. The pilot-operated mechanism ensures reliable operation under variable pressure conditions. Enhanced corrosion resistance with nickel-plated brass core components and chemical-resistant seals. Compatible with compressed air and inert gases (N₂ required for oxygen systems).
- Pneumatic cylinder control in automated assembly lines
- Vacuum generator systems for material handling
- Medical equipment gas flow control (requires medical-grade lubrication)
- Textile machinery air jet control systems
- Semiconductor manufacturing cleanroom automation
- Commercial coffee machine steam control
Installation requirements:
Use 5μm precision filter regulator. Maintain minimum 80mm clearance
below valve for condensate drainage. Lubricate with ISO VG32 turbine oil
if operating frequency exceeds 5Hz. Perform monthly manual cycling
during standby periods.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
