Airtac 3V2M Solenoid Valve 3V2MNCA-12F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-12F Solenoid Valve Specifications
- Model: 3V2MNCA-12F
- Type: 3/2-way normally closed (direct-acting)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure range: 0.05–0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.8W max | AC: 3.5VA max
- Flow coefficient (Cv): 0.8
- Response time: ≤15ms (excitation) | ≤20ms (de-energization)
- Seal material: Nitrile Butadiene Rubber (NBR) with PTFE backup rings
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP65 (coil) | IP40 (valve body)
- Electrical connection: DIN43650A standard plug
- Weight: 210g ±5g (including connector)
- Dimensions: 50mm (L) × 35mm (W) × 65mm (H)
High-speed response solenoid valve with low power consumption design, featuring a copper-free aluminum alloy body for lightweight corrosion resistance. The low-hysteresis plunger mechanism ensures precise flow control, compatible with compressed air and inert gases (N₂ required for oxygen systems). Includes manual override button for system debugging.
- High-cycle pneumatic grippers in robotics (300+ operations/minute)
- Dental chair pneumatic systems
- Semiconductor wafer handling equipment
- Beverage dispensing machine flow control
- Laboratory gas chromatography systems
Installation guidelines:
Mount with vibration-damping pads in high-frequency applications.
For vertical installation, position coil upward to prevent debris accumulation.
Use ISO 8573-1 Class 3 compressed air (max 5mg/m³ oil content).
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-12F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
