Airtac 3V2M Solenoid Valve 3V2MNCA-13F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-13F Solenoid Valve Technical Details
- Model: 3V2MNCA-13F
- Valve type: 3-way, 2-position normally closed (direct-acting)
- Port thread: G1/8 (BSPP) with optional NPT threads available
- Effective area: 13mm² (critical flow path dimension)
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 1.8W max | AC: 2.5VA max
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: High-grade HNBR rubber (-20℃ to 120℃)
- Body material: Reinforced PBT resin with UL94 V-0 flame rating
- Protection class: IP67 (dustproof & temporary immersion)
- Ambient temperature: -20℃ to 60℃ (non-freezing)
- Weight: 185g ±5g (without connector)
- Dimensions: 54mm(L) × 36mm(W) × 67mm(H) (including pneumatic ports)
- Port orientation: Axial inlet with perpendicular exhaust
- Manual override: Built-in push-button actuator
High-flow compact solenoid valve optimized for precision pneumatic systems requiring rapid cycling. Features a unique "snap-acting" armature design that reduces coil heating by 30% compared to standard models. The encapsulated coil assembly resists vibration-induced failures, making it suitable for mobile applications. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- High-speed textile machinery thread control
- Automated liquid dispensing systems
- Semiconductor wafer handling robots
- Electric vehicle battery cooling systems
- 3D printer pneumatic extruder controls
Installation guidelines:
Mount within 30° of vertical orientation. Use anti-vibration washers when
installed on platforms exceeding 2G acceleration. Allow 15mm clearance
on exhaust port side for heat dissipation. Lubricate seals with ISO VG32
pneumatic oil if used in high-cycle applications (>1Hz).
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-13F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
