Airtac 3V2M Solenoid Valve 3V2MNCA-15F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-15F Solenoid Valve Technical Details
- Model: 3V2MNCA-15F
- Function type: 3/2-way normally closed (direct-acting)
- Port configuration: PT1/4 (G1/4 ISO228-1 compliant)
- Effective area ratio: 1:1.15 (enhanced for low-pressure stability)
- Operating pressure range: 0.1–1.0 MPa (extended range for vacuum applications)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃ rated)
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Seal material: FDA-compliant NBR (optional FKM available)
- Ambient temperature: -5℃ to 80℃ (with 1℃ hysteresis)
- Protection rating: IP67 (submersible up to 1m for 30min)
- Housing material: Reinforced PBT with UL94 V-0 rating
- Weight: 235g ±5g (including coil)
- Dimensions: 52mm(L) × 38mm(W) × 72mm(H) (excluding fittings)
- Port thread depth: 12mm (prevents cross-threading during installation)
- Response time: ≤15ms (at 0.5MPa)
High-performance compact solenoid valve featuring dual-chamber design for reduced pressure loss (ΔP ≤0.02MPa). The brass core tube with hard chrome plating ensures 10M+ cycle durability. Special shock-absorbing structure minimizes chatter in high-vibration environments. Compatible with inert gases (N2/CO2) and requires 5μm filtered dry air.
- Robotic end-effector pneumatic grippers
- Beverage filling machine nozzle control
- Lithium battery production dry room systems
- Semiconductor wafer handling vacuum/pressure switching
- Railway brake system pilot valves
Installation protocol:
For horizontal mounting, use support bracket AIV-15F-01 (sold separately).
Lubricate O-rings with silicone grease (P/N: AG-7) during maintenance.
Minimum 12V DC requires 18AWG wiring for ≤3m runs.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-15F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
