Airtac 3V2M Solenoid Valve 3V2MNCA-16F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNC-A-16F Solenoid Valve Technical Details
- Model: 3V2MNCA-16F
- Type: 3/2-way normally closed (pilot-operated with manual override)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.15–1.0 MPa (extended range vs standard models)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (Cv=1.5) at 0.5MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 380g ±5% (with coil)
- Dimensions: 63mm(L) × 42mm(W) × 78mm(H) (excluding fittings)
- Seal material: High-grade HNBR rubber (-20℃ to 80℃)
- Body material: Reinforced PA66 with glass fiber (30%)
- Protection class: IP67 (dustproof & temporary immersion protection)
- Electrical connection: DIN43650A standard connector
- Service life: ≥10 million cycles (under rated conditions)
High-flow industrial solenoid valve featuring dual-chamber pilot structure for reliable switching under variable pressure conditions. The aluminum alloy coil housing provides enhanced heat dissipation, while the hardened stainless steel plunger ensures wear resistance. Compatible with ISO 15407-1 standards for pneumatic valve mounting interfaces.
- Plastic injection molding machine cylinder control
- CNC pneumatic clamping systems
- Industrial washing equipment pressure regulation
- Automated assembly line actuators
- Food processing pneumatic circuits (oil-resistant version available)
Installation guidelines:
- Mount in vibration < 1.5mm amplitude environments
- Use anti-vibration brackets when installed near motors/pumps
- Maintain 15° maximum deviation from vertical orientation
- Install upstream 5μm filter with automatic drain
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-16F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
