Airtac 3V2M Solenoid Valve 3V2MNCA-18F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-18F Solenoid Valve Technical Details
- Model: 3V2MNCA-18F (3V2M series)
- Valve type: 3/2-way normally closed (pilot-operated)
- Port configuration: PT1/8 (G1/8 optional)
- Effective area: 18mm²
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Response time: ≤15ms (excitation), ≤25ms (de-excitation)
- Seal material: NBR (Nitrile) standard, optional FKM/Viton
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Protection class: IP65 (dust-tight & water jet resistant)
- Weight: 220g ±5% (without connector)
- Dimensions: 54mm(L) × 34mm(W) × 68mm(H)
- Port thread depth: 10mm (minimum engagement)
High-flow solenoid valve with optimized pilot structure for rapid switching in compact pneumatic systems. Features brass body with hard anodized aluminum solenoid assembly, compatible with ISO 15407-1 standards. Requires 5-50μm filtered compressed air with lubrication (ISO 8573-1 class 4).
- High-speed sorting/pick-and-place robotics
- Plastic injection molding machine actuators
- Medical gas control systems (oxygen concentrators)
- Pneumatic clamping fixtures for CNC machining
- Beverage filling line control circuits
Maintenance tip:
For continuous operation (>4hrs daily), install vibration dampeners and perform
manual override testing monthly. Lubricate spool chamber every 2 million cycles
using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-18F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
