Airtac 3V2M Solenoid Valve 3V2MNCA-19F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-19F Solenoid Valve Specifications
- Model: 3V2MNCA-19F
- Type: 3/2-way normally closed (direct-acting)
- Port size: PT3/8 (G3/8 thread)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (on/off)
- Flow coefficient (Cv): 2.2
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (with 5℃ safety margin)
- Protection rating: IP67 (dust-tight, waterproof immersion up to 1m)
- Electrical connection: DIN43650 Form A
- Weight: 230g ±5g
- Dimensions: 58mm(L) × 38mm(W) × 72mm(H)
- Housing material: Reinforced PBT with UV protection
High-flow solenoid valve with ruggedized design for industrial environments. Features zero-pressure start capability and surge protection circuitry. Optimized for rapid cycling (up to 5Hz) with brass core tube for enhanced heat dissipation. Requires 5μm filtered compressed air with max 1% oil content.
- CNC machine tool pneumatic systems
- Plastic injection molding machines
- Industrial robotic arm end-effectors
- Food processing automation lines
- Semiconductor manufacturing equipment
Installation guidelines:
Mount with vibration-damping gaskets in high-shock environments.
For horizontal installation, orient coil upward at ≥15° angle to prevent debris accumulation.
Minimum 15mm clearance recommended for maintenance access.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-19F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
