Airtac 3V2M Solenoid Valve 3V2MNCA-1F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-1F Solenoid Valve Technical Details
- Model: 3V2MNCA-1F
- Type: 3/2-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (open), ≤20ms (close)
- Weight: 220g ±5% (without connector)
- Dimensions: 56mm(L) × 38mm(W) × 72mm(H)
- Seal material: FKM (Viton) / NBR optional
- Temperature range: -10℃ to 80℃ (NBR), -20℃ to 150℃ (FKM)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 15407-1 standard
High-flow compact solenoid valve with manual override, featuring brass body with anodized aluminum coil housing. Designed for medium-pressure pneumatic systems requiring fast cycling (up to 5Hz). Includes LED status indicator and surge protection. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- CNC machine tool clamping systems
- Automated assembly line actuators
- Textile machinery air control
- Plastic injection molding machines
- Food processing pneumatic circuits (FKM seal version)
Installation guidelines:
Mount in vibration-free environment with ±5° tolerance from vertical position.
Use copper-free lubricant for FKM seals. Allow 15-minute run-in period
after installation for optimal performance.
Critical note:
Not compatible with phosphate ester fluids or ketone-based chemicals.
Minimum 70% duty cycle required for AC models. Always install upstream
moisture separator in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-1F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
