Airtac 3V2M Solenoid Valve 3V2MNCA-3F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-3F Solenoid Valve Specifications
- Model: 3V2MNCA-3F
- Type: 3/2-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.05–0.7 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 0.65
- Response time: ≤15ms (open), ≤20ms (close)
- Seal material: High-grade FKM (Viton®) fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (with intermittent operation up to 100℃)
- Protection rating: IP67 (dust-tight and protected against temporary immersion)
- Electrical connection: DIN43650 Form A connector
- Weight: 165g ±3g
- Dimensions: 48mm(L) × 32mm(W) × 62mm(H) (excluding connector)
- Port thread depth: 9.5mm (male thread)
- Maximum allowable leakage: ≤20 ml/min
High-performance compact solenoid valve featuring low power consumption (1.2W typical) and bubble-tight sealing. The copper-free aluminum alloy body with anodized surface treatment ensures corrosion resistance in humid environments. Designed for 5 million cycle durability with <0.5% failure rate under rated conditions. Requires 5μm filtered compressed air with lubrication (ISO 8573-1 class 3.4.2).
- Industrial automation assembly line actuators
- Semiconductor manufacturing equipment
- Refrigerant control in HVAC systems
- Precision pneumatic dispensing machines
- Hydroponic farming climate control systems
- Automotive brake system testing rigs
Installation guidelines:
Mount in vibration-free environment with flow direction arrow aligned.
Use 0.3-0.5Nm torque for port connections. For horizontal mounting,
install coil vertically upward. Allow 15-minute cool-down period after
continuous 8-hour operation.
Critical notes:
Not compatible with phosphate ester-based lubricants. Avoid rapid
pressure fluctuations exceeding 0.1MPa/sec. Install surge suppressor
when using AC coils to prevent contact oxidation.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-3F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
