Airtac 3V2M Solenoid Valve 3V2MNCA-4F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-4F Solenoid Valve Technical Details
- Model Code: 3V2MNCA-4F (Full designation: 3V2M-NC-A-4F)
- Valve Type: 3-port 2-position normally closed (Pilot-controlled)
- Port Thread: PT1/4 (BSPP) with ISO G1/4 adaptor compatibility
- Effective Sectional Area: 12.8mm²
- Operating Pressure Range: 0.05–1.0 MPa (7-145 PSI)
- Proof Pressure: 1.5 MPa
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation: Class F (155℃ rated)
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Seal Materials: Main seal - HNBR, secondary seals - FKM (Viton® equivalent)
- Ambient Temperature: -5℃ to 60℃ (with no freezing)
- Fluid Temperature: 0-60℃ (lubricated air recommended)
- Viscosity Range: ≤21 cSt
- Protection Class: IP67 (dust-tight, protected against temporary immersion)
- Electrical Connection: DIN43650 Form A with LED indicator
- Mounting Orientation: Any (horizontal/vertical)
- Weight: 480g ±5% (including coil)
- Dimensions: 78mm (H) × 50mm (W) × 43mm (D)
- Port Spacing: 25mm between inlet/exhaust, 18mm between control ports
High-flow pilot-operated solenoid valve with metal seal option, featuring anti-vibration design for industrial environments. The aluminum alloy body with hard anodized treatment resists chemical corrosion. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.2.4 purity standards. Manual override available via push-button actuator.
- Plastic injection molding machine clamp control
- CNC tool changers with rapid cylinder cycling
- Food processing pneumatic systems (oil-free version available)
- Railway brake system pilot valves
- High-cycle packaging line diverters (rated for 50 million operations)
Operational note:
Maintain 0.3-1.0 MPa operating pressure for optimal response.
Lubricate with ISO VG32 turbine oil if used in dry air systems.
Allow 15-minute cool-down after continuous 2-hour operation.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-4F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
