Airtac 3V2M Solenoid Valve 3V2MNCA-5F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-5F Solenoid Valve Technical Details
- Model: 3V2MNCA-5F (3V2M series)
- Valve type: 3-way, 2-position normally closed (Direct-acting)
- Port configuration: PT1/8 (G1/8 optional), M5 manifold base available
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 0.15 (Kv 0.13) at 0.5 MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: High-grade NBR (Nitrile) with stainless steel plunger
- Ambient temperature: -5℃ to 80℃ (operating fluid: -5℃ to 60℃)
- Power consumption: 1.2W (DC), 2.5VA (AC)
- Electrical connection: DIN43650 Form A with LED indicator
- Protection class: IP67 (dust/water resistant)
- Weight: 210g ±5g (without connector)
- Dimensions: 50mm (L) × 35mm (W) × 65mm (H)
Precision-engineered compact solenoid valve featuring dual-chamber design for stable actuation under variable pressures. The 3V2MNCA-5F incorporates a copper-free aluminum alloy body with anodized treatment, making it compatible with aggressive environments. Its direct-acting mechanism ensures reliable operation even at vacuum pressures (down to -100kPa). Requires 5μm filtered dry air with oil mist ≤1mg/m³.
- Automated assembly line clamping systems
- Textile machinery air circuit control
- Semiconductor wafer handling equipment
- Beverage filling machine nozzle control
- Dental chair pneumatic adjustments
Maintenance protocol:
Lubricate pivot points every 5000 operation hours using ISO VG32 turbine oil.
Avoid mounting near high-frequency vibration sources (>50Hz). For horizontal
installation, use bracket support PN AS-2201 (sold separately).
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-5F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
