Airtac 3V2M Solenoid Valve 3V2MNCA-7F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCA-7F Solenoid Valve Technical Details
- Model Code: 3V2MNCA-7F
- Valve Type: 3/2-way normally closed (pilot-operated)
- Port Thread: PT1/4 (G1/4 optional)
- Effective Section Area: 7mm²
- Operating Pressure Range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power Consumption: 1.6W (DC) / 3.2VA (AC)
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Flow Coefficient (Cv): 0.45
- Seal Material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Ambient Temperature: -5℃ to 60℃ (operating fluid temp -20℃ to 60℃)
- Protection Class: IP67 (dustproof and waterproof)
- Weight: 180g ±5g
- Dimensions: 50mm (L) × 34mm (W) × 65mm (H)
- Port Alignment: 14mm center-to-center (horizontal ports)
High-performance medium-flow solenoid valve with electromagnetic pilot control, featuring optimized spool structure for reduced pressure loss. The copper-free aluminum alloy body meets RoHS compliance, while the encapsulated coil design prevents fluid ingress. Requires 5μm filtration (40μm max) with lubricated or non-lubricated air. Includes manual override button for system debugging.
- Plastic injection molding machine ejectors
- CNC tool changers and spindle brakes
- Food processing pneumatic actuators
- Lithium battery formation equipment
- Elevator door safety interlocks
Installation guidelines:
Mount in vibration-free locations with coil upright. Use flexible tubing near valve ports to prevent stress transfer.
For continuous operation, maintain ambient temperature below 50℃ with 70% relative humidity maximum.
| Property | Property Value |
|---|---|
| sku | 3V2MNCA-7F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
