Airtac 3V2M Solenoid Valve 3V2MNCAI-16F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCAI-16F Solenoid Valve Technical Details
- Model: 3V2MNCAI-16F (Full designation: 3V2M-NC-AI-16F)
- Valve type: 3/2-way normally closed (pilot-operated)
- Port size: G1/8 (ISO228/1 standard) with 16mm interface width
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 1.2 (Kv 1.0) at 0.5MPa
- Response time: ≤20ms (energize), ≤15ms (de-energize)
- Seal material: NBR (Nitrile) with PPS coil housing
- Ambient temperature: -5℃ to 60℃ (operating fluid temp 0-60℃)
- Power consumption: 2.2W (AC), 2.8W (DC)
- Protection class: IP67 (dustproof/immersion resistant)
- Weight: 185g ±5g (without connector)
- Dimensions: 54mm(L) × 35mm(W) × 64mm(H)
- Port thread depth: 12mm (minimum engagement 9mm)
- Max cycling rate: 5Hz (300 cycles/minute)
High-performance compact solenoid valve featuring corrosion-resistant brass body with aluminum alloy core components. Designed for precision fluid control in industrial automation, its pilot-operated structure enables reliable operation under low differential pressure conditions (minimum 0.05MPa). The encapsulated coil provides enhanced moisture resistance, suitable for washdown environments.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum cup control systems for material handling
- Injection molding machine air circuits
- Beverage filling equipment pneumatic actuators
- Semiconductor wafer handling robotics
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (torque ≤0.8N·m).
Maintain minimum 15mm clearance for heat dissipation. Use 5μm air filter
with automatic drain. Lubricate with ISO VG32 turbine oil if required.
| Property | Property Value |
|---|---|
| sku | 3V2MNCAI-16F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC220V |
