Airtac 3V2M Solenoid Valve 3V2MNCEI-5F
2、Coaxial shut-off design ensures excellent sealing performance and high flow capacity; Requires no oil lubrication;
3、Equipped with manual override for simplified installation and commissioning;
4、Modular design with base mount enables multi-valve integration for space-saving configurations;
5、Centralized air supply and integrated wiring streamline troubleshooting during fault diagnosis;
6、Flexible and scalable configuration supports arbitrary combinations or expansion of valve quantities/types;
7、Dedicated base gasket design – Flipping the gasket does not allow NC/NO conversion.
Category: Solenoid Valves , Brand: AirTAC , Series: 3V2M
AirTAC 3V2MNCEI-5F Solenoid Valve Specifications
- Model: 3V2MNCEI-5F
- Type: 3/2-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.7 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 180g ±5g
- Dimensions: 52mm(L) × 34mm(W) × 65mm(H)
- Seal material: FKM (Viton) / NBR optional
- Temperature range: -5℃ to 80℃ (NBR), -10℃ to 150℃ (FKM)
- Power consumption: DC: 1.8W, AC: 2.2VA
- Response time: ≤15ms (open), ≤20ms (close)
- Protection rating: IP67 (coil part)
- Port thread material: Brass with electroless nickel plating
- Max. flow rate: 700 L/min (ANR)
High-frequency solenoid valve with low power consumption design, featuring manual override and surge protection. The reinforced coil structure ensures 1 million+ cycle durability. Requires 5μm filtered air with lubrication (ISO VG32 recommended). Compatible with vacuum applications when using FKM seals.
- High-speed sorting machines in logistics systems
- Textile machinery thread control
- Semiconductor wafer handling robots
- Automated coffee machine brew units
- Electric vehicle battery cooling systems
Installation note:
For horizontal mounting, use the anti-vibration bracket (AVB-5 accessory).
Maintain 15mm minimum clearance below valve for manual override operation.
Lubricate O-rings with silicone grease during maintenance.
| Property | Property Value |
|---|---|
| sku | 3V2MNCEI-5F |
| Position | 3-Port 2-Position |
| Initial Position | Normally Closed |
| Standard Voltage | AC24V |
