Airtac 3V300 Solenoid Valve 3V31008NCA-AM
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve - 3V31008NCA-AM Technical Details
- Model: 3V31008NCA-AM (3V300 platform)
- Valve type: 5/3-way closed center, double solenoid
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 420g ±5% (without connectors)
- Dimensions: 98mm(L) × 38mm(W) × 53mm(H)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature tolerance: -5℃ to 80℃ (with dry air)
- Response time: ≤20ms (at 0.5MPa)
- Flow capacity: 850 l/min (Cv=1.2)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A
- Manual override: Built-in emergency switch
- Power consumption: 2.8W (DC24V), 4.5VA (AC)
High-flow 5/3-way pneumatic valve engineered for complex directional control systems. Features triple-coil protection against voltage spikes and a copper-free aluminum alloy body meeting ISO15407 standards. The pressure-balanced spool design ensures stable operation under fluctuating loads. Requires 5μm filtration (40μm for basic use).
- Multi-axis pneumatic actuator control in CNC machinery
- Plastic injection molding machine clamp systems
- Automated production line sequencing circuits
- Test bench pressure regulation modules
- Bottle filling station diverters
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Lubricate air supply (ISO VG32 recommended) if operating below 0℃.
Allow 15mm side clearance for heat dissipation during continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | 3V31008NCA-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
