Airtac 3V300 Solenoid Valve 3V31008NCBG-AM
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCBG-AM Technical Details
- Full Model Number: 3V31008NCBG-AM
- Valve Type: 3-position 5-way (center closed)
- Operation Mode: Double solenoid with spring return
- Port Thread: PT1/4 (G1/4 optional)
- Pressure Range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage Variants: DC12V/24V ±10%, AC110V/220V ±10% 50/60Hz
- Flow Capacity: 1200 NL/min (ANR) at 0.5 MPa
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Seal Material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient Temp Range: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Protection Class: IP67 (dustproof & temporary immersion)
- Electrical Connection: DIN43650 Form A with LED indicator
- Weight: 320g ±5g (without accessories)
- Dimensions: 55mm(W) × 40mm(D) × 82mm(H)
- Port Spacing: 18mm between pilot ports, 25mm between air ports
Industrial-grade 5/3-way valve featuring center-block design for precise cylinder control in mid-position. The 3V31008NCBG-AM incorporates dual manual overrides and surge protection circuitry, with brass body construction for corrosion resistance. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with 1-2 drops/10m³ oil mist recommended.
- Robotic arm clamping/positioning systems
- Plastic injection molding machine actuators
- Automated assembly line transfer units
- Textile machinery tension control
- Bottle capping/palletizing systems
Installation Best Practices:1. Mount horizontally with coil facing downward to prevent debris accumulation
2. Maintain 50mm clearance above valve for heat dissipation
3. Use flexible tubing with vibration dampeners in high-cycle applications (>5Hz)
4. Perform monthly manual cycling during maintenance
| Property | Property Value |
|---|---|
| sku | 3V31008NCBG-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
