Airtac 3V300 Solenoid Valve 3V31008NOB-AM
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300-08NOB-AM Solenoid Valve Specifications
- Model: 3V31008NOB-AM
- Type: 3/2-way normally open (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Fluid medium: Compressed air (lubricated or non-lubricated)
- Temperature range: -5℃ to 80℃ (with intermittent peaks up to 100℃)
- Seal material: HNBR rubber (hydrogenated nitrile)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow rate: 750 l/min (ANR) at 0.5 MPa
- Protection rating: IP67 (dust tight, protected against temporary immersion)
- Weight: 220g ±5g (with connector)
- Dimensions: 54mm(L) × 35mm(W) × 76mm(H)
- Port thread depth: 10mm (minimum engagement)
High-flow solenoid valve with manual override, featuring a brass body with hard-anodized aluminum core for corrosion resistance. The direct-acting design ensures reliable operation in low-pressure systems (down to 0.15 MPa). Includes LED status indicator and surge protection circuitry. Requires 5μm filtered air with max 5 ppm oil content.
- High-cycle pneumatic automation systems (800+ operations/hour)
- Food processing equipment with washdown requirements
- Mobile hydraulic control units with vibration exposure
- Plastic injection molding machine nozzle controls
- Laboratory pressure regulation systems
Installation guidelines:
Mount in any orientation (prefer vertical). Use flexible tubing to absorb vibration.
For continuous operation, maintain ambient temperature below 60℃. Replace air filters
every 2,000 operating hours in humid environments.
| Property | Property Value |
|---|---|
| sku | 3V31008NOB-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
