Airtac 3V300 Solenoid Valve 3V31008NOBG-AM
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NOBG-AM Technical Specifications
- Full Model Code: 3V31008NOBG-AM
- Valve Type: 3/2-way normally open (direct-acting with spring return)
- Port Configuration: G1/8 (ISO228/1 standard)
- Body Material: Die-cast aluminum alloy with hard anodized finish
- Seal Material: Heat-resistant NBR (Nitrile) - Optional FKM available
- Operating Pressure Range: 0.1-1.0 MPa (14.5-145 PSI)
- Proof Pressure: 1.5 MPa (217.5 PSI)
- Voltage Tolerance: ±10%
- Voltage Options:
- DC: 12V, 24V
- AC: 110V 50/60Hz, 220V 50/60Hz
- Power Consumption: 2.5W (AC), 3.2W (DC)
- Response Time: ≤15ms (energized), ≤20ms (de-energized)
- Ambient Temperature: -5℃ to 60℃ (23℉ to 140℉)
- Medium Temperature: 0℃ to 60℃ (32℉ to 140℉)
- Flow Rate (ANR): 650 L/min at 0.5 MPa
- Port Thread Depth: 12mm (male threads)
- Protection Class: IP67 (dust tight & protected against temporary immersion)
- Mounting Orientation: Any (universal installation)
- Weight: 0.42 kg (0.93 lbs) ±3%
- Dimensions: 52mm(W) × 45mm(H) × 84mm(L)
- Electrical Connection: DIN43650 Form A with flying leads (300mm length)
- Cycle Life: ≥10 million operations
High-flow solenoid valve optimized for rapid cycling in industrial automation systems. Features anti-vibration design with copper-aluminum composite coil winding for stable performance in high-shock environments. Includes manual override button for system debugging. Requires 5μm filtered compressed air with oil mist lubrication (ISO8573-1 Class 3.4.2).
- Pneumatic punching/stamping machine controls
- Robotic arm end-effector actuation
- CNC machine tool clamping systems
- Plastic injection molding ejectors
- Beverage canning line diverters
Installation Guidelines:
- Install downstream filter regulator (FRL unit) within 1 meter
- Apply 20-30Nm torque during port connection
- For horizontal piping: maintain 3° downward slope for condensation drainage
- Minimum 15mm clearance required around coil for heat dissipation
- Lubrication: Every 5 million cycles (use ISO VG32 turbine oil)
- Diaphragm inspection: Annual replacement recommended
- Coil resistance check: Verify 85Ω ±5% (24V DC model)
| Property | Property Value |
|---|---|
| sku | 3V31008NOBG-AM |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
