Airtac 3V300 Solenoid Valve 3V31008NOBG-W
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NOBG-W Technical Details
- Model: 3V31008NOBG-W (3V300 platform)
- Valve type: 3/2-way normally open with manual override
- Port configuration: G1/8 (ISO228/1 standard)
- Effective section area: 18mm²
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (AC), 2.8W (DC)
- Max flow rate: 650 l/min (ANR) at 0.5MPa
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: High-grade HNBR (Hydrogenated Nitrile)
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Fluid temperature: 0–60℃
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5g (without connector)
- Dimensions: 58mm(L) × 36mm(W) × 75mm(H) (manual operator adds 12mm)
- Mounting: Direct piping or sub-base (ISO 5599-1 compatible)
- Port thread depth: 12mm (minimum engagement 9mm)
High-flow solenoid valve optimized for industrial automation systems requiring rapid cycling (up to 5Hz). Features anti-vibration coil design with surge protection and gold-plated terminals. The manual override allows mechanical actuation during power failures. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Plastic injection molding machine ejectors
- CNC tool changers with pneumatic clamps
- Beverage canning line actuators
- Lithium battery production vacuum systems
- Automotive tire assembly robotics
Maintenance protocol:
Replace air filter elements every 2,000 operating hours. Use thread sealant
(Loctite 545 recommended) during installation. Avoid mounting near high-frequency
inverters (>20kHz) to prevent coil interference.
| Property | Property Value |
|---|---|
| sku | 3V31008NOBG-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
