Airtac 4F Foot Pedal Valve 4F210-08L
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Lockable variant available for applications requiring extended directional holding;
3. Robust locking mechanism ensures secure engagement with smooth quick-release action. Note: Structural constraints limit suitability for frequent high-impact scenarios;
4. Optional high-strength plastic protective cover enhances durability.
Category: Foot Valve , Brand: Airtac , Series: 4F
AirTAC 4F210-08L Foot Pedal Valve Technical Specifications
- Model: 4F210-08L
- Type: 3/2-way normally closed foot-operated valve (mechanical actuation)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Flow capacity: 1,200 NL/min (ANR) at 0.5 MPa
- Actuation force: 50-70N pedal pressure
- Body material: Die-cast aluminum alloy with hard anodizing
- Seal material: Oil-resistant NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃ (non-freezing environment)
- Mounting type: Base plate installation (M5 mounting holes)
- Weight: 0.82 kg ±3%
- Dimensions: 150mm(L) × 80mm(W) × 40mm(H)
- Response time: ≤0.3s (full stroke operation)
- Protection rating: IP54 (dust protected & water splashed)
Heavy-duty foot-operated valve featuring anti-slip pedal surface and stainless steel return spring. The dual-bearing hinge design ensures smooth operation over 500,000 cycles. Optimized flow path reduces air turbulence by 18% compared to previous generation models. Requires 5-40μm filtered compressed air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Production line fixture clamping/release control
- Packaging machine emergency stop systems
- Medical bed height adjustment mechanisms
- Automotive assembly tool activation
- Food processing equipment requiring hands-free operation
Installation guidelines:
Mount on stable surfaces with vibration dampeners. Lubricate pivot points every 3 months using ISO VG32 hydraulic oil.
For vertical mounting, install drainage port downward. Maximum allowable side load on pedal: 15N.
| Property | Property Value |
|---|---|
| sku | 4F210-08L |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
