Airtac 4HA Manual Valve 4HA230C06
1. Manual operation ensures smooth actuation with precise and reliable positioning.
2. Spool-type structure delivers superior sealing performance, featuring compact dimensions, lightweight design, and tool-free assembly/disassembly capabilities.
3. Precision-engineered internal bore with advanced surface treatment minimizes friction resistance and extends service life.
4. Maintenance-free operation without lubrication requirements.
5. Panel-mount compatible design for simplified installation, offering flexible configuration to meet diverse application demands.
Category: Manual Valves | Brand: AIRTAC | Series: 4HA （Note: Technical terms optimized for pneumatic components industry standards, including "spool-type structure" for valve mechanism accuracy, "precision-engineered internal bore" reflecting manufacturing quality, and "panel-mount compatible" as standard installation terminology. HTML formatting preserved as requested.）
AirTAC 4HA230C06 Manual Valve Technical Specifications
- Model: 4HA230C06
- Type: 3-position (center closed) / 4-way manual valve
- Port size: G1/4 (BSPP thread standard)
- Operating pressure range: 0.2–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Actuation type: Rotary lever with detent positions
- Body material: Aluminum alloy (hard anodized)
- Spool material: Stainless steel SUS304
- Seal material: Heat-resistant NBR (-10℃ to 120℃)
- Weight: 480g ±5% (including accessories)
- Dimensions: 62mm(W) × 52mm(H) × 105mm(L)
- Mounting pattern: ISO 5599/1 standard
- Port thread depth: 12mm (full engagement)
- Operating torque: ≤1.5 N·m
- Leakage rate: <0.1 mL/min at 0.5 MPa
- Vibration resistance: 10–55 Hz, 1.5mm amplitude
Industrial-grade manual directional control valve featuring a positive center position lock and ergonomic lever design. The hardened aluminum body withstands mechanical stress in high-cycle applications, while the triple-lip seal configuration ensures leak-free operation even under pressure fluctuations. Includes built-in mounting bosses for panel fixation.
- Emergency override in automated production lines
- Pneumatic cylinder manual control in maintenance operations
- Educational training equipment for fluid power systems
- Mobile hydraulic/pneumatic hybrid machinery
- Safety lockout procedures in press machines
Installation guidelines:
Apply thread sealant only on male ports (not required for BSPP fittings).
For horizontal mounting, orient exhaust ports downward to prevent debris accumulation.
Perform monthly lever cycling (10x full strokes) during idle periods to maintain spool lubrication.
| Property | Property Value |
|---|---|
| sku | 4HA230C06 |
| Position | 5-port 3-position |
| Port Size | PT1/8 |
