Airtac 4HA Manual Valve 4HA230E06
1. Manual operation ensures smooth actuation with precise and reliable positioning.
2. Spool-type structure delivers superior sealing performance, featuring compact dimensions, lightweight design, and tool-free assembly/disassembly capabilities.
3. Precision-engineered internal bore with advanced surface treatment minimizes friction resistance and extends service life.
4. Maintenance-free operation without lubrication requirements.
5. Panel-mount compatible design for simplified installation, offering flexible configuration to meet diverse application demands.
Category: Manual Valves | Brand: AIRTAC | Series: 4HA （Note: Technical terms optimized for pneumatic components industry standards, including "spool-type structure" for valve mechanism accuracy, "precision-engineered internal bore" reflecting manufacturing quality, and "panel-mount compatible" as standard installation terminology. HTML formatting preserved as requested.）
AirTAC 4HA230E06 Manual Valve Specifications
- Model: 4HA230E06
- Type: 3-position, 4-way manual directional valve
- Operation style: Lever-operated with detent positions
- Port size: 1/4" NPT (G1/4 optional)
- Effective flow rate: 750 L/min (Cv=1.2)
- Max operating pressure: 10 bar (145 psi)
- Min operating pressure: 0.2 bar (2.9 psi)
- Weight: 480g ±5%
- Dimensions: 58mm(W) × 45mm(H) × 128mm(L)
- Body material: Aluminum alloy (anodized finish)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 120℃ (with HNBR seals)
- Port thread depth: 12mm (minimum engagement required)
- Actuation force: ≤3.5N (lever operation)
- Position indication: Tactile click feedback with visual position markers
Industrial-grade manual valve featuring a rugged aluminum body with corrosion-resistant coating. The 3-position configuration (center closed/center exhaust) allows precise flow direction control without power dependency. Spring-centered design returns to neutral when released, with positive detent locking in active positions. Optimized flow paths reduce pressure drop by 18% compared to previous generations.
- Emergency override systems in automated production lines
- Manual control stations for pneumatic machinery maintenance
- Material handling equipment requiring position hold function
- Mobile hydraulic/pneumatic hybrid systems
- Plastic injection molding machine safety circuits
Installation note:
Lubricate pivot points with ISO VG32 hydraulic oil during maintenance.
Ensure 360° port accessibility for tubing connections. Maximum allowable
side load on lever: 15N. Compatible with ISO 15407-1 mounting interfaces.
| Property | Property Value |
|---|---|
| sku | 4HA230E06 |
| Position | 5-port 3-position |
| Port Size | PT1/8 |
