Airtac 4M Solenoid Valve 4M110-M5-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M110-M5-A Solenoid Valve Technical Details
- Model: 4M110-M5-A
- Valve type: 5/2-way monostable (spring return)
- Port thread: M5 × 0.8 (G1/8 equivalent flow)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (exhaust to actuation)
- Flow capacity: 450 l/min (Cv=0.48) @ 0.5MPa
- Weight: 185g ±5g (without connector)
- Dimensions: 52mm(L) × 38mm(W) × 78mm(H)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Housing material: Glass-filled nylon (UL94 V-0)
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (at rated conditions)
High-speed 5-port pneumatic valve optimized for compact automation systems. Features dual-color status LED (red/green) for visual feedback and manual override button for system debugging. The low-inertia plunger design enables 20% faster cycling than standard models. Requires ISO 8573-1:2010 Class 3.4.2 compressed air.
- Robotic gripper actuation systems
- Pharmaceutical blister packaging machines
- PCB handling vacuum generators
- Textile machinery air cylinder control
- Beverage canning line diverters
Installation protocol:
Mount on ISO 15407-1 compliant sub-base using M4 fasteners (1.2-1.5Nm torque).
Maintain ≥15mm clearance below valve for exhaust dispersion. Use only with
AirTAC VF-04 series filters for optimal performance.
| Property | Property Value |
|---|---|
| sku | 4M110-M5-A |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | AC220V |
