Airtac 4M Solenoid Valve 4M110M5B
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M110M5B Solenoid Valve Technical Specifications
- Model: 4M110M5B (4M Series Compact Valve)
- Valve type: 5/2-way, double solenoid pilot-operated
- Port configuration: M5 threaded ports (ISO 228 G1/8 equivalent flow)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (at 0.5MPa)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Weight: 280g ±5% (including coil)
- Dimensions: 54mm(L) × 36mm(W) × 68mm(H) (body only)
- Mounting spacing: 22mm between port centers
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥20 million cycles (under rated conditions)
High-speed 5-port solenoid valve optimized for precision pneumatic sequencing. Features dual manual override buttons, LED status indicator (on select models), and corrosion-resistant aluminum alloy body. The 4M110M5B incorporates a "Power Balance" pilot mechanism for consistent operation under pressure fluctuations. Requires 5μm filtered lubricated air (ISO 8573-1 Class 3.4.2).
- Multi-axis pneumatic cylinder control in assembly robots
- Vacuum cup release systems in glass handling equipment
- Mold clamping sequence control in injection molding machines
- Packaging line diverters with rapid cycle requirements
- Cleanroom-compatible medical device actuators
Installation protocol:
Mount horizontally with ports downward to prevent debris accumulation.
Use copper-free anti-seize compound on threads. Maintain 20mm clearance
above valve for coil maintenance. Always install downstream surge suppressors
for electrical protection.
| Property | Property Value |
|---|---|
| sku | 4M110M5B |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC24V |
