Airtac 4M Solenoid Valve 4M120-M5-B
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M120-M5-B Solenoid Valve Technical Details
- Model: 4M120-M5-B
- Valve type: 5/2-way mono-stable (single solenoid)
- Port configuration: M5 threaded (ISO 228-1)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (Cv=1.2 at 0.5MPa)
- Response time: ≤20ms (energize), ≤15ms (de-energize)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Body material: Reinforced PBT with glass fiber
- Weight: 210g ±5g (with coil)
- Dimensions: 52mm(L) × 35mm(W) × 65mm(H)
- Protection class: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599-1 standard compliant
- Manual override: Optional paddle-type actuator
High-flow directional control valve featuring rapid switching and low power consumption (≤2.2W). The dual-chamber design prevents pressure shock damage, with gold-plated terminals enhancing corrosion resistance. Compatible with ISO 8573-1:2010 Class 3 compressed air quality (max 5mg/m³ oil content).
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery air circuit control
- Beverage filling station actuator control
- Automated welding equipment
- Semiconductor handling robots
Maintenance protocol:
Lubricate spool every 5 million cycles using ISO VG32 turbine oil.
Avoid axial twisting during piping - use swivel fittings for angled connections.
| Property | Property Value |
|---|---|
| sku | 4M120-M5-B |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC24V |
