Airtac 4M Solenoid Valve 4M120M5BI
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M120M5BI Solenoid Valve Specifications
- Model: 4M120M5BI
- Type: 5/2-way single solenoid pilot-operated
- Port size: 1/4" (G1/8 thread equivalent)
- Port configuration: M5 subminiature ports
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.48 kg (1.06 lbs)
- Dimensions: 60mm(L) × 45mm(W) × 78mm(H)
- Valve body material: Reinforced PBT resin with glass fiber
- Seal material: Heat-resistant NBR (Nitrile) rubber
- Temperature range: -5℃ to 60℃ (operating fluid), -20℃ to 80℃ (ambient)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Flow capacity: 750 l/min (Cv=1.2 at 0.5MPa)
- Protection rating: IP67 (dustproof & temporary immersion protection)
- Electrical connection: DIN43650 Form A connector
The 4M120M5BI features a unique low-power dual-coil design with surge protection, optimized for high-cycle automation systems. Its corrosion-resistant construction and IP67 rating make it suitable for harsh environments. The valve incorporates a manual override and status LED indicator. Requires 5μm filtered dry air with 30-40% oil mist lubrication recommended.
- High-speed packaging machine actuators
- PCB handling robotic arms
- Lithium battery production line automation
- Cleanroom-compatible medical device controls
- Plastic injection molding ejector systems
- Semiconductor wafer processing equipment
Installation note:
Mount in vibration-free position using M4 screws (max torque 1.2N·m).
Maintain ≥15mm clearance around exhaust ports. For horizontal mounting,
use optional mounting bracket (Model: MB-4M). Lubricate sliding parts
with ISO VG32 turbine oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 4M120M5BI |
| Position | 5 Ports 2 Position |
| Port Size | M5 |
| Standard Voltage | DC24V |
