Airtac 4M Solenoid Valve 4M210-06-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M210-06-A Solenoid Valve Specifications
- Model: 4M210-06-A
- Type: 5/2-way double solenoid (internal pilot)
- Port size: PT3/8 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including coil)
- Dimensions: 54mm(L) × 54mm(W) × 83mm(H)
- Flow coefficient (Cv): 1.6
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 100℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
- Max operating frequency: 5Hz (with 50% duty cycle)
High-flow 5/2-way valve with dual solenoid operation, featuring aluminum alloy body with hard anodized coating for industrial durability. The T-shaped spool design ensures stable switching under vibration conditions. Requires 5μm filtered/dried compressed air (ISO 8573-1:2010 class 4.4.3) with lubrication optional.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine actuators
- CNC tool changer positioning systems
- Textile machinery cylinder control
- Automotive brake testing equipment
- Food processing pneumatic circuits (oil-free version available)
Installation guidelines:
Mount with M5 screws (recommended torque 2.0N·m). Maintain 20mm clearance
above valve for heat dissipation. Use shielded cables for EMI-sensitive
environments. Manual override requires 2.5mm hex key operation.
Critical notes:
Do not disassemble under pressure. Allow 30-second cool-down between
continuous operations exceeding 5Hz. Compatible with ISO VG32 hydraulic oil
for lubrication (max 1,000 cSt viscosity).
| Property | Property Value |
|---|---|
| sku | 4M210-06-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
