Airtac 4M Solenoid Valve 4M21006B
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M21006B Solenoid Valve Technical Details
- Model: 4M21006B
- Type: 4-way, 5-port (3-position closed center)
- Port size: G1/8 (BSPP thread)
- Operation mode: Double solenoid or single solenoid with spring return
- Effective sectional area: 17.5mm²
- Operating pressure range: 0.15–0.9 MPa (21.7–130.5 PSI)
- Proof pressure: 1.35 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.8W (DC), 3.2VA (AC)
- Response time: ≤20ms (excitation), ≤15ms (reset)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Seal material: Heat-resistant NBR (Nitrile)
- Body material: Reinforced PBT resin
- Weight: 280g ±5% (including coil)
- Dimensions: 55mm(L) × 42mm(W) × 78mm(H)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599-1 standard (CETOP RP52H)
High-flow 4-way pneumatic valve with center-block function, featuring a unique pressure-balanced spool design for consistent performance under varying loads. The aluminum oxide-resistant coil ensures stable operation in humid environments. Includes manual override and position indicator window for maintenance diagnostics.
- Double-acting cylinder control in automated assembly lines
- Clamping mechanisms in injection molding machines
- Pneumatic actuator control for valve banks
- Material handling systems with intermediate position requirements
- Cleanroom equipment requiring ISO 8573-1:2010 Class 2 air quality
Installation guidelines:
Mount horizontally with arrow direction matching airflow. Use 5μm filter with auto-drain.
For vertical mounting, install exhaust silencer downward. Lubricate with ISO VG32 turbine oil
if operating below 0℃. Minimum 20mm clearance required above coil for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 4M21006B |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
